In electrical engineering, the terms ground and neutral refer to circuit conductors used in alternating current (AC) electrical systems. The neutral conductor facilitates the flow of alternating current to and from the supply during the circuit's normal operation. To limit the effects of leakage current from higher-voltage systems, the neutral conductor is often connected to the earth ground at the point of supply. On the other hand, a ground conductor is not designed to carry current under normal conditions, but rather it connects exposed metallic components, such as equipment enclosures, to the earth ground. The ground conductor only carries a significant amount of current when there is a circuit fault that could potentially energize exposed conductive parts and create a safety hazard. In such cases, circuit protection devices may detect the fault and automatically de-energize the circuit or provide a warning.
Characteristics and Values Table
| Characteristics | Values |
|---|---|
| Normal circuit currents | Flow only in the neutral |
| Protective earth conductor | Bonds all equipment cases to earth to intercept any leakage current due to insulation failure |
| Neutral conductor | Connected to earth at the building point of supply |
| TN-C system | A common conductor provides both the neutral and protective grounding |
| Danger of TN-C system | A broken neutral connection will allow equipment cases to rise to a dangerous voltage if any leakage or insulation fault exists |
| Triplen harmonic currents | Additive, resulting in more current in the shared neutral conductor than in any of the phase conductors |
| Current in the shared neutral conductor | Can be triple that in each phase conductor |
| Ground conductor | Not intended to carry current for normal operation |
| Ground conductor | Connects exposed metallic components to earth ground |
| Ground conductor | Carries significant current if there is a circuit fault |
| Current | Only flows in complete loops |
| Current in the safety earth wire | Indicates an electrical fault |
| Purpose of safety earth wire | To pop breakers if a fault occurs |
| Ground-neutral in the building distribution panel | No current can flow since one connection doesn't make a loop |
| Current | Flows through the ground back to the generator |
| Fault current | Only flows into the ground path if a hot conductor is accidentally shorted to something connected to ground |
| Grounding systems | Minimise the voltage difference between neutral and local earth ground |
Explore related products
What You'll Learn
- The neutral conductor is often connected to earth ground at the point of supply
- A ground conductor is not intended to carry current during normal operation
- Current only flows in complete loops
- The TN-S system: separate neutral and protective earth conductors are installed
- The TN-C system: a common conductor provides both the neutral and protective grounding
The neutral conductor is often connected to earth ground at the point of supply
In electrical engineering, the neutral conductor and ground (or earth) are circuit conductors used in alternating current (AC) electrical systems. The neutral conductor receives and returns alternating current to the supply during normal circuit operation.
In the TN-S system, separate neutral and protective earth conductors are installed between the equipment and the source of supply. Normal circuit currents flow only in the neutral conductor, and the protective earth conductor bonds equipment cases to earth to intercept any leakage current due to insulation failure. The TN-C system, on the other hand, uses a common conductor for both neutral and protective grounding. While the neutral conductor is connected to earth ground at the point of supply, there is no common path to ground for the circuit current in the TN-S and TN-C systems.
In a TT system, each piece of electrical equipment or building distribution system has its own connection to earth ground, and there is no lengthy common protective ground conductor. Indian CEAR, Rule 41, specifies that the neutral conductor of a 3-phase, 4-wire system must have at least two separate earth connections to achieve satisfactory earth resistance.
Connecting the neutral to the equipment case can provide some protection against faults. However, if the neutral connection is broken, it may result in a dangerous voltage on the case. To ensure safety, special precautions may be necessary, such as frequent rodding down to earth, using cables where the combined neutral and earth surround the phase conductor(s), and thicker-than-normal equipotential bonding.
