Robots are physical systems that can perceive, reason about, and act upon their environment. They use sensors to understand internal signals and external surroundings. They are powered by electricity, which is shunted around the robot by its electronics. A circuit can be defined as a pathway for electricity to flow. For electricity to travel throughout a robot's body, there needs to be a complete and unbroken loop for electricity to flow, known as a closed circuit. This allows the robot to power on. If the loop is broken, electricity cannot flow, and the circuit is considered open. Voltage, current, and resistance are the three fundamental quantities in a circuit. Voltage creates current, or the flow of electricity through a circuit. Current is a count of the number of electrons flowing through a circuit, measured in amperes. Resistance is the difficulty of passing an electric current through an object, measured in ohms.
| Characteristics | Values |
|---|---|
| Electricity | Used for command, control, and at least one stage of actuation in robots |
| Electrical Circuits | A pathway for electricity to flow, similar to the human circulatory system |
| Power Source | A battery |
| Basic Electrical Devices | Buzzer, LED, and motor |
| Voltage | The amount of power in the power source, which determines the speed of electricity |
| Current | The actual electricity moving through the circuit |
| Resistance | The difficulty of passing an electric current through an object |
| Amps | The electrons in electricity that make things happen |
| Capacitors | Polarized capacitors can only be charged in one direction |
| Diodes | Zener diodes limit voltage to a safe value or provide a stable reference voltage |
| Programming | Robots can be programmed to perform a particular task |
| Sensors | Used to understand internal signals and external surroundings |
Explore related products
What You'll Learn
Electric circuits are the power source for robots
Robots use electricity for command, control, and actuation. They employ a range of electronic components, including resistors, capacitors, transistors, op-amps, logic gates, motor controllers, timing chips, memory chips, digital RF receivers, and communication protocol handlers. The design of circuits and chips, along with actuators and algorithms, enable robots to move and think.
When building a robot, it is important to understand the power requirements of the circuit. Each device on the circuit will draw a certain number of amps, and the total amp load needs to be considered when designing the circuit. Motors, for example, have a normal load and a peak load rating. Fusing can be added to the circuit to protect the power supply, motors, and devices from shorts, failures, and excessive current draw.
Additionally, the distinction between AC and DC power is important. AC power is typically supplied by a power company through a wall outlet, while DC power is supplied by batteries. DC motors can tolerate the voltage being run down to zero, and they can also handle slightly higher voltages. However, it is crucial to ensure that the wiring, connections, and power supply are sufficient to meet the amp demands of DC devices.
Understanding electrical circuits is fundamental to robotics, and it is a key area of research and education in electrical and computer engineering. By studying the basics of circuits, voltage, current, and resistance, as well as the power requirements of different components, one can design and build functional robots with various capabilities.
