The Pelton wheel, invented by American Lester Allan Pelton in the 1870s, is a type of impulse turbine used to generate electricity in hydropower plants. It is designed to work with a high hydraulic head and low flow rate, making it suitable for mountainous regions. The Pelton wheel converts the kinetic energy of water into mechanical energy, which is then converted into electrical energy by a generator. The wheel has a series of curved buckets or blades mounted on its periphery that capture the water jet and transfer its momentum to the wheel, spinning it and generating electricity through the connected generator.
| Characteristics | Values |
|---|---|
| Type of turbine | Impulse |
| Energy source | Moving water |
| Water head | 150-2000m |
| Water flow | Low |
| Water velocity | High |
| Runner | Series of curved buckets mounted on the outer periphery of a wheel |
| Bucket shape | Double hemispherical cup or bowl; two halves separated by a high ridge |
| Bucket function | Capture water jet, direct flow backwards, convert kinetic energy to mechanical energy |
| Spear/needle | Controls the flow of water through the nozzle |
| Efficiency | Up to 95% |
Explore related products
What You'll Learn
The role of impulse energy
The Pelton wheel, named after its inventor Lester Allan Pelton, is an impulse-type water turbine designed in the 1870s. It is a highly efficient mechanism for converting water energy into electricity, particularly in geographical locations with high hydraulic head and low flow rates. This makes it ideal for hydroelectric power generation, a significant form of renewable energy.
The Pelton wheel's unique design allows it to harness the impulse energy of moving water, marking a departure from traditional water wheels that relied on water's dead weight. The wheel consists of a circular disc with specially crafted buckets mounted on its periphery. These buckets, also known as impulse blades, are typically spoon-shaped and fixed side-by-side. Nozzles play a crucial role in enhancing the kinetic energy of the water directed at these buckets.
The high-speed water streams from the nozzles strike the impulse blades, causing the water's velocity to change direction and follow the contours of the blades. This change in velocity results in the impulse energy of the water jet exerting torque on the bucket-and-wheel system. Consequently, the wheel spins, and the impulse energy is transferred to a turbine, generating mechanical energy.
The innovative bucket design, with a divider known as a splitter, ensures that the water jet is split into two equal streams. This design feature eliminates counter-torque by preventing the water jet from pushing against the incoming flow. As a result, the Pelton wheel achieves maximum power and efficiency when the velocity of the water jet is twice that of the rotating buckets. This efficient conversion of impulse energy into mechanical energy is what ultimately enables the Pelton wheel to produce electrical power.
