Reading electrical plans and drawings can be challenging, often appearing as a confusing cluster of multicoloured lines, symbols, and abbreviations. However, it is a vital skill for electricians, engineers, and architects. To read electrical plans, one must familiarize themselves with the symbols, lines, and abbreviations used, and understand how these relate to electrical components such as resistors, capacitors, and power sources. Electrical plans may also include load calculations, wire size diagrams, and floor plans, which show the physical locations of wiring and outlets. Learning to read electrical plans takes time and practice, and one can refer to textbooks, online resources, or experienced individuals for help.
| Characteristics | Values |
|---|---|
| Symbols | Familiarize yourself with common electrical symbols and their meanings. Symbols vary and may include resistors, capacitors, transistors, switches, power sources, and more. |
| Diagrams | Single-line diagrams, electrical floor plans, and wire size diagrams are examples of diagram types used in electrical plans. |
| Load Calculations | Check for load calculations that specify the electrical service size based on the anticipated electrical load of the building or project. |
| Conventions | Learn the terminology, symbols, and conventions used in civil drawings to improve interpretation accuracy. |
| Software | SOLIDWORKS Electrical is a software that can assist in creating and understanding electrical schematics. |
| Colours | Colours are used to indicate the purpose of wires, e.g., green wires often indicate a connection going to ground. |
| Labels | Components, wires, and cables are assigned labels, tags, marks, or numbers for traceability and troubleshooting. |
| Abbreviations | Understand the abbreviations used in electrical drawings to interpret the conveyed message accurately. |
| Scale | Electrical plans are typically drawn to scale, except for electrical symbols, which may be enlarged for readability. |
| Updates | Electrical plans may require frequent updates or modifications compared to other aspects of construction drawings. |
Explore related products
What You'll Learn
Learn the meaning of symbols, lines, and abbreviations
When reading electrical plans, you will encounter a variety of symbols, lines, and abbreviations that convey information about electrical systems, wiring, appliances, and more. Here's what you need to know to interpret them correctly:
Symbols:
Each symbol represents a specific electrical component, such as outlets, switches, lights, fans, or appliances. For example, a circle connected to a wall by two parallel lines represents a typical outlet or receptacle with two sockets. Outlets for larger appliances may be indicated by a triangle, with abbreviations indicating the intended appliance, such as CD for a clothes dryer, CW for a clothes washer, DW for a dishwasher, or R for a refrigerator. A television is often denoted by the letters "TV" in a box.
Lines:
Lines in electrical plans indicate wiring connections and routes. Curving dashed lines connecting switches and fixtures show the approximate path of wiring throughout the building. These lines provide a general understanding of how the wiring will be routed but do not represent precise locations. The continuous line represents the wiring connection required for equipment.
Abbreviations:
Abbreviations are used to denote specific appliances or electrical systems. For example, "GFCI" stands for "ground-fault circuit interrupter," an outlet with a built-in circuit breaker to prevent electric shocks, typically used near water sources. Numbers next to symbols provide additional information, such as "220" indicating a 220-volt outlet. The text "R1, R2, R3," and so on, near symbols with continuous lines indicates specific fixture symbols.
It's important to note that while standard symbols are commonly used across engineering offices, each office may have its own unique set of electrical symbols. Therefore, it is essential to refer to the legend sheet or symbol key provided with the plans to interpret the specific symbols, lines, and abbreviations used in a given set of electrical drawings.
