Microcontrollers are used to automate electric doors in various settings, from homes to shopping malls, offering convenience, security, and energy efficiency. This technology relies on sensors, microcontrollers, motor drivers, and motors. When a person approaches, the sensor detects their body heat or motion, sending a signal to the microcontroller, which activates the motor driver to open the door. After a delay, the microcontroller reverses the motor's direction, closing the door. This process eliminates manual control, enhances security, and reduces energy consumption. Microcontrollers can also be used for password-based door lock systems, where access is granted upon entering the correct code.
| Characteristics | Values |
|---|---|
| System Type | Automatic Door Opening System |
| Function | To open and close doors automatically |
| Sensors | PIR, Infrared, Pressure, Ultrasonic, Laser, Motion |
| Microcontroller | 8051, AT89C52, Arduino Uno |
| Power Supply | 5V DC, 9V DC battery, 12V, 1A adaptor |
| Components | Motor, LCD Display, DVD, Resistor, Capacitor, Transformer, Diode, Crystal, Transistor |
| Software | Keil compiler, Embedded C, Assembly, PictoBlox |
| Applications | Security, Home Automation, Energy Efficiency |
Explore related products
What You'll Learn
Using an 8051 microcontroller
An 8051 microcontroller can be used to automate an electric door. This can be achieved by using a PIR (Passive Infra-red) sensor to detect the presence of a person and then sending a signal to the microcontroller to activate a motor driver, which in turn operates the door's motor.
The PIR sensor detects the difference between room temperature and body temperature in the form of a change in infrared radiation. This change in the infrared pattern is converted to a voltage, which is then sent to the microcontroller for processing. The microcontroller then activates the motor driver, which controls the operation of the motor. The L293D Motor Driver is a dual H-bridge motor driver integrated circuit (IC) that can drive two motors simultaneously in both forward and reverse directions.
The 8051 microcontroller can be used in a password-based door lock system. In this system, a person must enter the correct code or password to gain access to a secured area. If the correct password is entered, the microcontroller activates the door motor to open the door and displays the status on an LCD screen. If the password is incorrect, the door remains closed, and "PWD is wrong" is displayed.
The 8051 microcontroller requires a supply voltage of +5V DC, which can be provided by a 7805 power supply circuit and a 9V DC battery or 12V, 1A adapter as a power source. The reset pin of the microcontroller must be kept active until the power supply is within the specified range, and a minimum oscillation level is maintained.
The automatic door opening system using the 8051 microcontroller can be implemented in various places, such as shopping malls, railway stations, and airports, to eliminate manual control of doors. This system can also be enhanced with additional features like face detection for security applications.
