AutoCAD Electrical is a powerful tool that enables users to create and manage electrical designs efficiently. One of its key features is the ability to work with catalogues, allowing for easy access to various electrical components and their associated data. Adding a catalogue in AutoCAD Electrical involves several steps, including creating a new table in the catalogue database, defining subassembly quantities, and setting up symbols for the catalogue items. Additionally, AutoCAD Electrical supports secondary catalogues, providing the option to store manufacturer part numbers separately, which can be useful for organizing custom and out-of-the-box information. In this guide, we will explore the process of adding a catalogue to AutoCAD Electrical, covering the necessary steps and best practices to enhance your design workflow.
| Characteristics | Values |
|---|---|
| Command to add a new table to the catalog database | Expand the Other Tools panel on the Project tab |
| Default catalog database name | default_cat.mdb |
| Table name suggestion | Secondary_cat.mdb |
| Table fields | Field order, length, and type |
| Table name and description | Added to the _FAMILY_DESCRIPTION table in the catalog database |
| _FAMILY_DESCRIPTION table usage | Used by the Catalog Browser and Symbol Builder to show the description for a catalog table/symbol category |
| SYMBOL2D | Used in AutoCAD Electrical |
| SYMBOL3D | Used when inserting parts in Inventor when the project is linked to an Inventor assembly |
| PEERCOILPINS and PEERPINLIST fields | Applicable when the catalog value can have two parent symbols |
| PINLIST | Written to the database in the format required by the program |
| Assembly quantity | Defined by entering a number in the ASSEMBLYQUANTITY field |
| Quantity definition for each subassembly with multiple ASSEMBLYCODE values | Prefix the ASSEMBLYCODE value code with the quantity followed by a comma |
| TEXTVALUE field | Used to assign values to attributes when the catalog is assigned to a component |
| Secondary catalog | Allows users to store additional manufacturer part numbers in a separate database |
Explore related products
What You'll Learn
Adding a new table to the catalog database
To add a new table to the catalog database in AutoCAD Electrical, you need to first ensure you are working on an active project with the main catalog database that you want to edit.
Next, go to the "Project" tab and select the "Other Tools" panel. From the drop-down menu, select the "Add Table to Catalog Database" command, or type "AEADDCATALOGTABLE" in the command line.
Once the command is activated, a pop-up window will appear where you can select the catalog database you want to edit. If you want to modify the default catalog database, select the "default_cat.mdb" file. After selecting the database, click "OK".
The table will then be added to the database with the correct fields, including field order, length, and type. The table name and description will also be added to the _FAMILY_DESCRIPTION table in the catalog database.
To see the changes reflected in the Catalog Browser, you need to exit and restart AutoCAD Electrical. Once restarted, your new category will appear in the Catalog Browser, and you can begin adding catalog data to your new table.
