There are various methods to building an electric mouse trap, with some being more complex than others. A simple method involves using a charged-up capacitor, which can be thrown at the mouse to deliver a zap. A more complex method involves creating a circuit with a transistor oscillator, a high-frequency step-up transformer, and a voltage multiplier. Another option is to use a car battery connected to a capacitor and two sheets of aluminum or steel, with positive and negative connections. For those looking for a non-electric alternative, wrapping the trunk of the tree with a smooth, slippery surface like polyethylene sheet or aluminum can also be effective in deterring rats.
| Characteristics | Values |
|---|---|
| Type of trap | Electric shock |
| Purpose | To kill the mouse or rat |
| Power source | 4 AA batteries |
| Voltage | 12V |
| Additional components | Voltage generator, AC Capacitor, aluminium/steel sheets |
| Bait | Peanut butter |
| Safety considerations | Disconnect battery when not in use to prevent fire risk and risk of electrocution |
Explore related products
$31.49 $34.99
$29.99 $57.71
$17.99 $19.99
What You'll Learn
- Use a 12V battery, connect it to a capacitor, then to two sheets of metal
- Create a circuit with a transistor oscillator, high-frequency transformer, and voltage multiplier
- Use a charged capacitor or a bug zapper tennis racket to scare rodents
- Set up a motion sensor to control the switch and delay the zap
- Use conductive pads (electrodes) with one connected to hot and the other to neutral
Use a 12V battery, connect it to a capacitor, then to two sheets of metal
To build an electric mouse trap, you will need a 12V battery, a capacitor, two sheets of metal, wire mesh, a switch, and a wooden board.
First, cut the wooden board to the desired size, ensuring it can accommodate all the components. Next, attach the wire mesh to the board using screws or nails. This will serve as the platform for the mouse to walk on.
Now, it's time to create the electrical circuit. Connect one end of the wire to the positive terminal of the 12V battery and the other end to the switch. Then, connect another wire from the switch to the wire mesh.
Take the 12V battery and connect it to a capacitor. You can use a 150 uF AC Capacitor. The capacitor will then connect to two sheets of metal, with the positive connection going to one sheet and the negative to the other. These sheets of metal will be placed an inch or two apart, so when the mouse walks across them, it completes the circuit and receives a shock.
It is important to note that some sources suggest that a 12V battery may not be sufficient to produce a shock. You may need additional components, such as a transistor oscillator, a high-frequency step-up transformer, and a voltage multiplier, to create an effective electric mouse trap.
