Building an electric supercharger at home is a challenging endeavour that requires careful planning and technical expertise. It involves using a high output motor, such as a 50,000 RPM 40 KW motor, and a dedicated high-voltage battery system, which can be expensive. The project also demands a thorough understanding of turbochargers, battery management, and electronic speed controllers. While similar technology exists in F1 cars, it is often proprietary and combined with conventional turbos for optimal performance. Enthusiasts have shared their experiences and insights on forums, offering glimpses into the complexities and costs of such DIY projects. Before embarking on this project, it is essential to evaluate the potential gains, costs, and time investments required to achieve desired results.
Explore related products
Sourcing parts
- Electric Motor: The electric motor is a crucial component of your supercharger, and you will need a high-output motor capable of delivering significant power. You can consider using a high-RPM, high-KW motor similar to those used in high-end radio-controlled models. These motors can be sourced from hobby shops or online retailers specialising in remote-controlled vehicles. Alternatively, you may want to explore options such as the torqamp, which has been mentioned by DIY enthusiasts.
- Battery System: The battery system is another essential part of your setup. You will require a dedicated battery system capable of delivering high voltage, such as 48 volts. Lithium-polymer batteries, similar to those used in electric cars, can be considered. These batteries can be charged slowly from the car's electrical system, minimising the load on the engine. Keep in mind that batteries can be expensive, so it is important to carefully evaluate your options and consider the cost-benefit ratio. Alibaba has been suggested as a possible source for batteries and other electronic components.
- Electronic Speed Controller (ESC): The ESC is responsible for regulating the speed of your electric supercharger. It is a critical component that ensures the safe and efficient operation of your setup. The ESC should be compatible with your chosen motor and battery system. When sourcing an ESC, pay attention to its specifications, such as voltage and current handling capabilities, to ensure it can handle the demands of your supercharger.
- Compressor: The compressor is the heart of your supercharger, responsible for pressurising the air entering the engine. You can explore options such as the PanDair General Supercharger, which is a turbocharger turbo remanufacturing kit compatible with various engine sizes. Alternatively, you can consider using the compressor side of a vortec supercharger, as mentioned by some DIY enthusiasts.
- Adapters and Connectors: Depending on the specific vehicle you are working with, you may need adapters and connectors to interface your supercharger with the engine. For example, if you are working with a Tesla, you may require specific adapters to integrate your supercharger effectively. Ensure that you research the specific requirements of your vehicle and source the necessary adapters to ensure a seamless installation.
It is important to note that building a homemade electric supercharger can be a complex and costly endeavour. Always prioritise safety and consult with experts or online communities with experience in this field to ensure that your setup is safe and reliable.
