AutoCAD Electrical is a powerful tool that allows users to create and insert symbols representing electrical components such as relays and switches. These symbols can be tied together in various family relationships, including parent/child and siblings, enabling efficient design and build processes. To create AutoCAD Electrical symbols, users should open the Block Editor, utilize the Symbol Builder Attribute Editor to place attributes and connections, and then perform a symbol audit to ensure functionality. Saving symbols with the correct coding, such as V or H to indicate vertical or horizontal orientation, is crucial. Additionally, users can insert symbols by attaching them to the cursor, selecting the location, and assigning catalog values. These symbols can be added to the icon menu and Catalog Browser, facilitating easy access and insertion during projects.
| Characteristics | Values |
|---|---|
| Connecting symbols | Symbols representing components like relays can be connected, creating parent/child relationships. |
| Symbol creation | To create a symbol, draw the required geometry and select the ‘Symbol Builder’ icon. |
| Symbol Builder Attribute Editor | This panel allows you to place ‘Required’ and ‘Optional’ attributes, ‘Wire’ connections and ‘Link’ connections. |
| Symbol audit | Once all attributes and connections are placed, a symbol audit is carried out to ensure the symbol will work. |
| Symbol library | Symbols can be saved into a custom symbol library using the correct coding, e.g. V or H for Vertical or Horizontal. |
| Symbol insertion | Symbols can be added to the icon menu and Catalog Browser. |
| Symbol sharing | Symbols can be shared and used on any project. |
Explore related products
What You'll Learn
Creating symbols
AutoCAD Electrical allows users to create symbols representing components like relays and establish parent-child relationships between them. The Symbol Builder tab in AutoCAD Electrical enables the creation of custom symbols and facilitates linking them to each other. This feature ensures that the symbols can carry Device ID and BoM information, enabling cross-referencing and easy navigation between different components.
To create symbols in AutoCAD Electrical, start by accessing the Symbol Builder tab. Here, you'll find various tools and options to design and customise your symbols. You can add specific shapes, lines, and details to represent the component accurately. Utilise the available templates or create your own from scratch.
When designing symbols, consider the industry standards and conventions to ensure consistency and clarity in your electrical diagrams. Standardisation of symbols is crucial for effective communication and collaboration in engineering projects. Ensure that the symbols are visually distinct and easily recognisable, especially when dealing with complex electrical systems.
Once you've finalised the design of your symbol, the next step is to define its properties and behaviour. This includes assigning a unique name or identifier, setting the scale, and specifying any associated data or attributes. You can also establish relationships between symbols, such as parent-child connections, to build a comprehensive library of interconnected symbols.
After customising and configuring your symbol, the final step is to save it. Choose a designated path or folder to store your custom symbol library. This organised approach ensures easy access and retrieval of your symbols for future projects. It also enables you to build a comprehensive symbol library, facilitating efficient electrical design and documentation. With your symbols set up, you can now utilise them in your AutoCAD Electrical drawings, creating clear and informative representations of electrical systems.
