Building an electric jet turbine is no small feat, but it's possible to do it yourself with the right tools and knowledge. The basic principle behind an electric jet engine is similar to that of a turbojet engine, but instead of using a second turbine to add power to the compressor, it relies on electric power. To build one, you'll need to understand how jet engines work, and then gather the necessary materials and equipment, which may include a CNC machine, a welder, a cutting torch, and various metalworking tools and techniques. You'll also need to decide on a design, whether it's based on an existing engine or something more innovative, and ensure it has the necessary components, such as a turbine, compressor, combustion chamber, and exhaust. With the right knowledge, skills, and dedication, you too can build an electric jet turbine.
| Characteristics | Values |
|---|---|
| Materials | Stainless steel, mild steel, aluminium, nickel alloys, cardboard, body filler, hard wire, glue, paint |
| Tools | Omax water-jet cutter, vertical band saw, drill press, TIG welder, CNC machining equipment, 3D printer |
| Components | Compressor, combustion chamber, flame tube, exhaust turbine, intake turbine, shaft, bearings, fuel control lever, DC motor, gearbox, flywheel, electromagnet coil, magnets |
| Process | Research jet engine theory and watch videos of homemade versions, design the engine, cut and weld metal parts, machine and bolt together components, connect fuel and starter |
| Power Source | Electric power, fuel ignition |
Explore related products
What You'll Learn
Understanding the basic principles of jet engines
The basic principle of jet engines is centred around jet propulsion, which involves compressing air with an inlet and a compressor, mixing fuel with the compressed air, burning the mixture, and then passing the hot, high-pressure air through a turbine and a nozzle to generate thrust.
Jet engines can be broadly categorized into airbreathing jet engines and rocket engines. Airbreathing jet engines, which are commonly used in aircraft, rely on atmospheric air to provide oxygen for combustion. They can be further classified into turbojet engines and turbofan engines. Turbojet engines work by compressing air with a compressor, mixing it with fuel, igniting the mixture, and then passing the exhaust gases through a turbine to generate thrust. Turbofan engines are similar but differ in that not all the air entering the compressor passes through the combustor and turbine.
Turbofan engines are generally more efficient than turbojet engines, especially at speeds just below the speed of sound. The development of turbofan engines has significantly improved fuel efficiency, enabling routine transatlantic flights by twin-engined airliners.
Rocket engines, on the other hand, do not require atmospheric air and can operate at arbitrary altitudes and even in space. They carry all the components of the reaction mass, including the oxygen needed for combustion. Ramjet engines are a type of airbreathing jet engine with no moving parts in the engine proper, only in the accessories. They require an initial forward airspeed to function and are considered the simplest type of airbreathing jet engine.
