The electrical axis in an ECG represents the major direction of the overall electrical activity of the heart. The QRS axis is the most important to determine, but the P wave or T wave axis can also be measured. The normal cardiac axis is directed downward and slightly to the left, with the QRS axis between -30° and +90°. To calculate the electrical axis, the mean QRS axis is oriented towards the lead with the greatest net QRS deflection, which is calculated by adding the number of small squares corresponding to the height of the R wave and subtracting the squares corresponding to the Q and S waves. The standard multilead system used in veterinary medicine is the hexaxial lead system, formed by six limb leads.
Explore related products
What You'll Learn
The normal axis range
To calculate the electrical axis, the mean QRS axis is identified by locating the lead with the greatest net QRS deflection. This involves adding the small squares corresponding to the height of the positive deflection (R wave) and subtracting the squares corresponding to the negative deflection (Q and S waves). This calculation helps determine the overall electrical activity of the heart, which can be normal or exhibit deviations like left axis deviation (LAD), right axis deviation (RAD), or an indeterminate northwest axis.
In veterinary medicine, the normal mean electrical axis varies by species. For dogs, the normal range is between +40° and +100°, while in cats, it spans from 0° to +160°. These ranges are determined using the hexaxial lead system, which consists of six limb leads, including bipolar leads I, II, and III, and unipolar leads aVR, aVL, and aVF.
It is important to note that the normal axis range in an ECG can vary depending on the specific context and the age of the patient. For example, in paediatric ECG interpretation, the cardiac axis lies between +30° and +190° at birth and gradually moves leftward as the child ages. Therefore, it is always essential to refer to specific guidelines and interpretations for the particular situation when interpreting ECG results.
