The power cord is one of the most vital components of a vacuum cleaner, so when it comes to a Dyson, it's important to know how to replace it. A frayed or damaged power cord can cause a dangerous electrical mishap, so it's crucial to act fast. Replacing the power cord on a Dyson vacuum cleaner can be a straightforward task if you proceed with caution and follow instructions meticulously. This guide will take you through the steps to safely replace a Dyson power cord, including what tools you'll need and how to avoid common pitfalls.
| Characteristics | Values |
|---|---|
| When to replace the cord | When there are frays or cuts on the cord, when there is exposed wiring, when the vacuum stops working sporadically, or when there is a burning odour coming from the cord |
| What you will need | A replacement cord from an electronics service centre, a Phillips screwdriver, electrical tape, and a multimeter (optional) |
| Step-by-step process | 1. Unplug the vacuum from the wall socket. 2. Remove the vacuum canister from the front of the vacuum. 3. Remove the hose. 4. Remove the four 15mm screws with a Torx T15 screwdriver. 5. Press in the two tabs towards the centre and remove the face of the power supply. 6. Remove the black case to access the power cord. 7. Remove the power cord by gripping the plastic parts. 8. Install the new power cord by wrapping the exposed end of the wire around the loosened screws. 9. Tighten the screws. 10. Reattach the casing and screws. |
Explore related products
What You'll Learn
Unplug the vacuum and remove the canister
Unplugging the vacuum and removing the canister are the first steps to take when replacing a Dyson electric cord. This process will differ depending on the model of your Dyson vacuum.
For a Dyson DC14, begin with the vacuum unplugged, standing upright, and facing towards you. Remove the canister from the vacuum. Disconnect the telescopic vacuum wand. Remove the two T15 Torx screws securing the switch cover to the vacuum. Push outward on the two plastic clips that secure the switch cover to the vacuum. Remove the switch cover from the vacuum.
If you have a Dyson DC07, start by unwrapping the power cord. Detach the handle of the vacuum cleaner by pressing the release button. Pull the handle from the hose. Slide the hose down the wand and push the button at the bottom to release the hose from the machine. Press the button at the top of the dust bin handle to remove the canister bin assembly from the Dyson DC07. Lay the machine on its back with the power switch facing upward.
For a Dyson Ball Animal, turn off and unplug the vacuum. Remove the vacuum canister from the front of the vacuum. Flip the vacuum around and remove the hose so it is not blocking the back of the vacuum. There are four 15mm screws that must be removed with a Torx T15 screwdriver. After all the screws are released, there are two tabs that must be pressed in and towards the centre. The tabs can be pressed in one at a time but may require some force.
Electric Brake Caliper Bleeding: DIY Guide
You may want to see also
Explore related products
Remove the outer casing and locate the power cord
To remove the outer casing and locate the power cord, start by unplugging the Dyson vacuum cleaner from the wall outlet. Press the button on the top front of the plastic collection cover. Lift and remove the cover from the front of the vacuum cleaner. Trace the power cord to where it enters the back bottom of the vacuum cleaner.
Using a screwdriver, locate and unscrew the screws that hold the outer casing in place. Keep these screws in a safe place for later reassembly. Gently lift and remove the outer casing from the vacuum body. Be careful not to damage any interconnected components during this process.
Once the casing is removed, you will see the power cord connected to the main circuitry. Follow the black cord from the power cord and remove it from the metal tongue by pinching the plastic piece. Grab the power cord from the plastic parts, not the cord itself. There may also be a black case that needs to be opened to access the power cord fully.
Now, you can begin the process of replacing the power cord. Make sure to wrap the exposed end of each wire of the new power cord around the loosened screws and tighten them securely.
Repairing Ryobi Electric Pressure Washers: A Step-by-Step Guide
You may want to see also
Explore related products
Disconnect the wires and remove the cord
Before disconnecting the wires and removing the cord, it is important to unplug the Dyson vacuum cleaner from the wall outlet to avoid any risk of electric shock.
Now, to disconnect the wires and remove the cord, first, locate the wires connected to the power switch. Firmly pull the wires from the power switch while holding them by their white plastic coverings. Be sure to grip the wires from their attached connectors, as pulling directly on the wires could damage the vacuum.
Next, remove the plastic terminal covers that shield the female ends of the power cord wires. You may need to use a flat-head screwdriver to lift the wires free from the connectors. Once the wires are disconnected, you can remove the cord from the vacuum.
If your Dyson vacuum is a DC14 model, there may be additional steps required to disconnect the wires. You will need to remove the canister and disconnect the telescopic wand before accessing the wires. Additionally, the purple switch button may separate from the rest of the switch cover, so take care when removing it.
It is important to note that you should not force the plastic-covered connectors from the switch, as this could break the male ends. Pull them off gently but firmly to avoid causing any damage.
Electric Fireplace TV Stands: Are They Safe?
You may want to see also
Explore related products
Thread the new cord and reconnect the wires
Threading a new cord and reconnecting the wires is a straightforward task, but it must be done meticulously to ensure your safety and the longevity of your Dyson vacuum cleaner. Before you begin, make sure you have a compatible replacement power cord for your specific Dyson model.
First, you will need to remove the outer casing of your Dyson vacuum. Using a screwdriver, locate and unscrew the screws that hold the outer casing in place. Gently lift the outer casing off the vacuum body, being careful not to damage any interconnected components. Once the casing is removed, you will have access to the power cord connected to the main circuitry.
Now, it's time to thread the new power cord. Follow the existing cord's path and remove any protective covers or plastic parts that might be blocking the new cord. Make sure to grab the old cord from these plastic parts and not the cord itself to avoid damage. Once you have cleared the path, carefully thread the new power cord through, making sure it follows the same route as the old one.
Reconnect the wires from the new power cord to the switch. Reconnecting the wires typically involves inserting the male end of one wire into the female end of the other wire. Make sure to align the wires in the correct channels to prevent them from being pinched or pulled out during reassembly. Refer to the user's guide or a photo of the original wiring configuration if you're unsure.
After reconnecting the wires, wrap electrical tape around the connections for added safety and to prevent short circuits. Now, you can begin to reassemble your Dyson vacuum cleaner. Carefully replace the outer casing, ensuring that all internal components are safely tucked away and not obstructed. Securely fasten all the screws back into place and double-check that everything feels sturdy.
Increasing Electricity Load: Punjab's Power Play
You may want to see also
Explore related products
Reassemble the vacuum and test
Once you have the new power cord in place, it's time to reassemble your Dyson vacuum and test it. Here's a detailed guide to help you through the process:
Reassembling the Vacuum:
Firstly, carefully replace the outer casing of your vacuum cleaner. Ensure that all the internal components are safely tucked away and not pinched or trapped by the casing. Use your screwdriver to securely fasten all the screws back into place. Double-check to make sure everything feels sturdy and aligned.
Testing the Vacuum:
After reassembling, reinsert the plug into the power socket. Turn on the vacuum and listen carefully for any strange noises or functioning issues. Observe the vacuum's performance and check for any unusual behaviour. If everything works smoothly, you have successfully replaced the power cord.
Safety Reminders:
When working with electrical appliances, safety should always be a top priority. Always disconnect your vacuum from the power source before attempting any repairs. Additionally, use electrical tape to secure connections and enhance safety, preventing short circuits. Before plugging in your repaired vacuum, ensure that all components are securely fastened and there are no exposed wires or loose parts.
Troubleshooting:
If you encounter any issues during the testing phase, don't hesitate to retrace your steps and double-check your work. Ensure that all connections are secure and that the new power cord is properly installed. Refer to the disassembly steps in reverse order to guide your reassembly process. If issues persist, consult a qualified technician or seek advice from a Dyson support service.
Electric Pepper Grinders: Worth the Cost and Hype?
You may want to see also
Frequently asked questions
Check for any frays, cuts, or exposed wiring on the cord. If the vacuum stops working while in use or emits a burning odour, it could be a sign of cord issues.
You will need a screwdriver, preferably a Phillips screwdriver, and a replacement cord that is compatible with your specific Dyson model.
First, ensure the vacuum is unplugged and disconnected from any power source. Then, remove the vacuum canister and hose. Locate and unscrew the outer casing screws and gently lift it off.
Once the casing is off, you will see the cord connected to the circuitry. Remove the cord protector and plastic covers on the cord wires. Disconnect the wires from the power switch, pulling from the white plastic coverings, not the wires. Wrap the new cord wires around the screws, tighten, and reconnect.
Reattach the outer casing, ensuring all components are secure and not pinched. Fasten the screws, then test the vacuum by plugging it in and turning it on. Listen for any strange noises.
