A multimeter is a device used to measure voltage, current, and resistance in an electrical circuit. It can also be used to test continuity, which refers to how much resistance there is in a closed electrical current. Testing continuity is important when installing or repairing electrical components to prevent fires, shocks, or damage to devices. To test continuity with a multimeter, first, make sure the device being tested is turned off and unplugged. Then, connect the black and red terminals of the multimeter to the corresponding slots: the black cord into the COM slot and the red cord into the mAVΩ or AVΩ slot. Next, turn the dial on the multimeter to the continuity setting, which is usually indicated by a diode symbol. Finally, position the multimeter probes on both sides of the connected area or joint being tested. If there is continuity, the multimeter will show zero resistance and may emit a beep. If there is no continuity, the meter will show infinite or high resistance and remain silent.
| Characteristics | Values |
|---|---|
| Purpose | To test continuity in a wire, current, or fuse when installing or repairing electrical components in an outlet, fuse box, car, or appliance |
| Multimeter Parts | Black terminal (ground), red probe (active current), LED display, ports for test leads (common, voltage/resistance, current, and sometimes milli- or micro-amps) |
| Preparation | Turn off, unplug, or flip the breaker on the signal being tested; remove battery from circuit |
| Steps | Stick two terminals against two ends of an electrical current, positioning probes on both sides of the connected area or joint being tested; turn dial to continuity setting (diode symbol or sound waves) or lowest number in resistance mode if no continuity setting |
| Expected Results | Continuous beep or faint, disjointed tone indicates continuity; no sound indicates no continuity |
| Troubleshooting | Check dial and ports if there is no beep or a high reading, then try replacing terminals; if the screen displays a 1 on the far left, the terminals may be bad |
Explore related products
What You'll Learn
How to position multimeter probes for testing
To position multimeter probes for testing, you must first ensure that your multimeter is in continuity mode and that the circuit you are testing is disconnected from its power source.
The next step is to identify the positive and negative terminals of the circuit. The black probe of the multimeter is the ground and is connected to the negative terminal, whereas the red probe is for the active current and is connected to the positive terminal.
If you are testing a switch, there should be no continuity reading when you flip the switch to the off position. When testing a fuse, place the red probe anywhere on the body of the fuse, but ensure that the two terminals do not touch as this will interfere with the reading.
For testing soldering, the red probe should be placed on the other end of the material being tested. If you are testing an appliance and wire connection for safety reasons, press the red terminal against the wire or fuse.
Wait for the numbers on the multimeter screen to stabilize, and then check the reading to get the resistance. A reading of 0 indicates perfect continuity.
