There are several ways to convert an electric plug to battery power, depending on the type of plug and the desired battery power source. If the plug is a standard US 120V outlet, for example, one may need to bypass the step-down transformer and rectifier to connect it to a battery. In some cases, a transformer may be required to convert AC to DC or DC to AC power. Additionally, the wattage and voltage requirements of the device need to be considered, as some devices may require full voltage to function properly. It is also important to carefully manage the connections to avoid short circuits. In some cases, it may be more feasible to use an AC pump or motor instead of converting to battery power.
Characteristics and Values Table for Converting Electric Plug to Battery
| Characteristics | Values |
|---|---|
| Use Case | To power devices that are usually battery-powered but don't need to be portable all the time |
| Example Devices | Battery-powered swings, lights, clocks, Christmas decorations |
| Power Supply | Old power adapter, AC adapter, car battery |
| Voltage | 1.25V to 1.5V per battery, 5.9V output voltage, 12V adapter |
| Connector | DC power jack with a built-in switch, XT60 or XT90 connector, cigarette lighter plug |
| Circuit Connection | Connect positive terminal of battery to pin 2 on power jack, negative terminal to pin 3 for common ground |
| Regulator Circuit | Connect positive output to one screw, negative output to another screw, mark polarities |
| Alternative | Use rechargeable AA battery converter for clocks and devices |
Explore related products
What You'll Learn
- Understand the electronics: Know the voltage and if it converts from AC to DC or vice versa
- Use a transformer: A transformer converts AC to DC or DC to AC power
- Use a regulator: A variable voltage regulator like LM317 can be used to match the circuit
- Connect the wires: Cut and connect the wires from the positive terminal of the battery pack to the power jack
- Use a battery converter: For AA battery-powered clocks or devices, a battery-to-electric converter can be used
Understand the electronics: Know the voltage and if it converts from AC to DC or vice versa
To understand the electronics of a plug conversion from electric to battery power, you need to know the voltage and whether it converts from AC (alternating current) to DC (direct current) or vice versa. Voltage is the pressure that pushes electricity through a circuit. The higher the voltage, the more electricity is flowing.
You can measure voltage with a digital multimeter, a small electronic device used to measure electrical properties such as voltage, current, and resistance. It is sometimes also known as a multitester. You can purchase a multimeter at a home improvement store, a hardware store, or anywhere tools are sold. Costs vary depending on precision; a basic handheld multimeter meant for non-professional, at-home use costs between $15 and $50.
To test voltage with a multimeter, set the device to measure voltage, insert one probe into each slot, and read the line voltage measurement. A properly grounded outlet registers voltage when one probe of a voltage detector or a multimeter is inserted into the small outlet slot, and the other probe is placed on the receptacle's center screw.
It is important to note that polarity, the direction of the flow of current, can also be important. A polarity test determines whether all the conductors in an electrical installation are properly connected and not mistakenly reversed, which can be dangerous. To do a polarity test, insert one probe of a voltage detector or a multimeter into the large slot and the other against the screw (scrape off any paint to ensure good contact). If the voltage detector lights, that means the hot and neutral wires are reversed, and the wiring should be further checked.
