Industrial electrical schematics are diagrammatic representations that provide guidelines on the setup, functioning, and service of an electrical circuit. They are important for electricians to be able to quickly and efficiently diagnose and resolve problems that may occur within an electrical system. This tutorial will cover the basics of how to read industrial electrical schematics, including how to identify common electrical symbols, understand the differences between wiring diagrams and schematic diagrams, and interpret the three main types of diagrams: wiring diagrams, schematic diagrams, and single-line diagrams.
| Characteristics | Values |
|---|---|
| Purpose | Electrical schematics provide guidelines on the setup, functioning, and service of an electrical circuit. They are used as a plan to create an electrical structure or system and to identify and resolve problems within an electrical system. |
| Users | Electricians, Heat Ventilation and Air Conditioning (HVAC) technicians, and machine operators. |
| Components | Each physical component (e.g. resistor, capacitor, transistor) has a unique schematic symbol. Component names are usually a combination of one or two letters and a number, with the letter identifying the type of component (e.g. R for resistor, C for capacitor). |
| Symbols | Different countries use different symbols to represent the same thing. Symbols are used to represent power sources (DC or AC), batteries, voltage nodes, terminals, switches, and logic gates. |
| Layout | Schematics can be split into functional blocks, with sections for power input, voltage regulation, microcontrollers, or connectors. The flow of the circuit is typically from left to right, with inputs on the left and outputs on the right. |
Explore related products
$10.99
What You'll Learn
Learn the standard symbols for components
Standard symbols are used in electrical schematics to represent components involved in distributing electrical power. These include powering motors, lights, heaters, and speakers. Wires, power sources, switches, relays, inductors, and grounding are all components that work together to make this happen. Each component has a unique name, and these names are usually a combination of one or two letters and a number. The letter part of the name identifies the type of component—for example, R's for resistors, C's for capacitors, and U's for integrated circuits.
There are several standard symbols that are important to know when reading electrical schematics. For example, a straight, featureless line represents a wire connecting one device to another. Connected wires are represented by solid junctions, while unconnected wires are indicated by one wire jumping over another. Symbols joined with a dot indicate an electric connection between components. Plus and minus symbols indicate a specific direction of charge, but only for DC. An S-shaped symbol (a wave symbol) indicates AC current. Arrows are also used within schematic symbols to indicate the direction of conventional current flow around a circuit or through a component. They can also be used to show that a component has a variable or adjustable value. For example, a potentiometer or rheostat.
It's important to note that while there are universally accepted schematic symbols for electrical components, there are also variants and alternative symbols used throughout the world to represent the same component. For example, the IEC (International Electrotechnical Commission) and IEEE (Institute of Electrical and Electronics Engineers) have different sets of symbols for the same components. The IEC database is one of the most comprehensive groups of schematic symbols relied upon by engineers worldwide and is accessible with a yearly subscription. The IEEE/ANSI standard was deprecated in 2019 but is still widely used, so engineers should reference it.
When creating new electronics, designers and engineers must use these standard symbols to describe the components used. These symbols are vital for sharing knowledge about applications of electric and electronic systems. They provide clarity, allowing engineers to communicate clearly with electricians about wiring and safety.
