AutoCAD is a computer-aided design software used to create 2D and 3D drawings, including electrical diagrams. Electrical symbols are a crucial component of these diagrams, representing various electrical components and devices. While some basic electrical symbols are included in the tool palette, users often need to insert additional symbols specific to their projects. This process can be done by accessing the Icon Menu under the Schematic tab and selecting the desired symbol, which can then be placed at the chosen location. Users can also create their own electrical symbols or download symbol libraries from third-party sources, such as ISA, to expand their repertoire of electrical symbols in AutoCAD.
| Characteristics | Values |
|---|---|
| To insert electrical symbols in AutoCAD | Open the Icon Menu, Schematic tab > Insert Components pane > Icon Menu |
| Selecting a symbol | Locate and select your desired symbol. The symbol will attach to your cursor, making insertion easy. |
| Inserting the symbol | Click on the desired location. The Insert/Edit dialog box will open. |
| Assigning a tag | The Tag is automatically assigned based on the Drawing Properties settings. |
| Assigning a catalog value | Click Lookup and assign the catalog value as needed. |
| Finalizing the insertion | Click OK. |
| Alternative method | Use the shortcut Ctrl+3 to access the ToolPalettes and find electrical symbols. |
Explore related products
What You'll Learn

Using the Icon Menu
To insert electrical symbols in AutoCAD, you can use the Icon Menu. Here's a step-by-step guide on how to do it:
The Icon Menu in AutoCAD allows you to insert electrical symbols into your drawings. To get started, open the Icon Menu by going to the Schematic tab on the ribbon, then clicking on the Insert Components pane, and finally selecting Icon Menu.
Once the Icon Menu is open, you can locate and select the electrical symbol you want to use. The symbol will be attached to your cursor, making it easy to insert into your drawing. Simply click to select the location where you want the symbol to appear.
After selecting the location, the appropriate Insert/Edit dialog box will open. Here, you can review or modify the symbol's properties. The Tag is automatically assigned based on your Drawing Properties settings. If needed, you can use the Lookup feature to assign a specific catalog value to the symbol.
Finally, click OK to place the symbol in your drawing. If everything is set up correctly, any associated wires will break as needed.
You can also add your own custom symbols to the Icon Menu. When creating a new symbol, you can define its insertion point in the format file. This will determine the coordinate value at which the symbol is inserted. Additionally, you can utilise the Symbol Builder Attribute Editor to insert and modify AutoCAD Electrical toolset attributes.
By following these steps, you can easily insert electrical symbols into your AutoCAD drawings using the Icon Menu, customising and placing them exactly where you need them.
