Electric potential, also known as voltage, is a scalar field that provides information about the energy landscape produced by an electric field. It is represented by a single number at each point in space, making it easier to graph than electric fields. Electric potential-distance graphs are used to determine the potential difference between two points, with the X-axis representing the distance from the charge and the Y-axis representing the electric potential. The area under the E-r graph between two points is equal to the potential difference. The electric potential increases as the charge increases and decreases as you move away from the charge.
| Characteristics | Values |
|---|---|
| Electric potential | Scalar field |
| Electric potential | A single number at each point in space |
| Electric potential | Dependent on the position of the object |
| Electric potential | Directly proportional to the amount of charge |
| Electric potential | Inversely proportional to the distance |
| Electric potential | Positive charge, positive potential |
| Electric potential | Negative charge, negative potential |
| Electric potential | Zero for both positive and negative charges when infinitely far away from the charge |
| Electric field strength | 1/r2 relationship |
| Electric potential vs distance graph | The x-axis shows the distance away from the charge, the y-axis shows the electric potential at a certain point |
Explore related products
$53.91 $99.99
What You'll Learn
Electric potential is a scalar field
The electric field is a vector field that any charge will produce. A scalar field, on the other hand, is a concept that describes the energy landscape that the electric field produces. Positive charges can be thought of as hills, and negative charges as valleys in this landscape. The electric potential is like a topographic map of the space surrounding the charges in question.
The electric potential is the electric potential energy per unit charge. This value can be calculated in either a static (time-invariant) or dynamic (time-varying) electric field at a specific time, with the unit joules per coulomb (J⋅C−1) or volt (V).
In some contexts, electric potential is not a scalar but a component of a 4-vector. It is not invariant with respect to boosts. However, the potential is just one component of the four-vector, and it is a scalar under the rotation group and more generally under the Galilean Group.
The electric field can be expressed as both the scalar electric potential and the magnetic vector potential. The electric potential and the magnetic vector potential together form a four-vector, so the two kinds of potential are mixed under Lorentz transformations.
Calculating Excess Electrical Capacity: Understanding Your Energy Usage
You may want to see also
Explore related products
Electric potential vs distance graphs
