Metals are electrical conductors, meaning they have low resistance and high conductance. The resistance of a metal is dependent on its size, shape, temperature, and the number of free electrons in its atomic lattice. Measuring the resistance of a metal is important for determining the condition of a circuit or component. This can be done using a digital multimeter, which measures resistance using either a constant current or constant voltage. The constant current technique is generally used for resistance values below 200M ohms, while the constant voltage technique is used for high resistance measurements.
Explore related products
What You'll Learn
Using a digital multimeter
To measure the electric resistance of metals using a digital multimeter, follow these steps:
Firstly, ensure that the component you are testing is isolated from the circuit. Either remove the component or isolate it with an open switch. This is important because the resistance of all components connected in parallel with the component being tested will affect the resistance reading, typically lowering it.
Next, check that your multimeter is in good condition. Make sure the battery is fully charged, and look for any signs of corrosion. Check your multimeter for any cracks, and check the wires for any fraying or nicks.
Now, insert the black test lead into the COM jack, and the red lead into the VΩ jack. If your multimeter has a selector knob, turn it to the Ω setting. If your multimeter has a RANGE button, press it to select a specific fixed measurement range.
Then, connect the test leads across the component being tested. Ensure that contact between the test leads and the circuit is good. If you are testing a resistor, hold the probes against the resistor legs with the same amount of pressure you use when pressing a key on a keyboard.
Finally, observe the readout window to obtain the Ω reading. Compare the results to the manufacturer’s Ω specifications. If the readings match the component, then resistance is not a problem. If the component is a load, there should be resistance that matches the manufacturer’s specs. If the reading is infinite (I) or overloaded (OL), then the component is open. If the reading is zero, then the component is closed (if it is a load, this indicates an internal short).
It is important to note that the human body conducts electricity, so always handle only the insulated part of the probe while testing resistors. If you are measuring very low resistance, use the relative mode (REL) to automatically subtract test lead resistance.
