Electrical backfeed to a transformer is a potentially dangerous practice that involves sending electricity in the reverse direction through a transformer. This can be done to provide temporary power in emergency situations, but it is generally not recommended due to the risk of high excitation inrush, which can cause coordination issues with breakers or fuses and result in lower output voltages. When measuring electrical backfeed, it is important to consider the type of transformer, the voltage levels, and the potential impact on the wider electrical system. This complex process requires careful evaluation of the protection system and relay settings to ensure safe operation in reverse mode.
| Characteristics | Values |
|---|---|
| Recommended practice | Backfeeding a general-purpose transformer is not recommended, especially for transformers smaller than 3Kva. |
| Industrial Control Transformers | Backfeeding is not allowed for any Industrial Control Transformers of any size, as windings are compensated and backfeeding will result in lower than expected output voltage. |
| Excitation Inrush | Backfeeding causes very high excitation inrush, making coordination to breakers or fuses difficult without exceeding the limits set by the National Electrical Code. |
| Delta-Wye Transformer | If backfeeding a Delta-Wye transformer, do not connect the neutral terminal to the primary system neutral or ground. |
| Taps | When backfed, taps do not help compensate for poor (other than nominal) source voltage to provide the appropriate magnetic flux levels in the core as they are designed to do. |
| Delta Primaries | If all transformers have delta primaries, there should be no problem. |
| Wye Primary Transformer | There are problems feeding a wye primary transformer from a delta system. |
| Delta/Wye Transformer | Problems arise when a delta/wye transformer is back fed. |
| Two-Winding Transformer | A two-winding transformer energizing from the lower voltage side of a power transformer will see issues at the lower voltage side, namely higher inrush current, high neutral current, and a higher voltage drop. |
| Solutions | Energize with a full winding by increasing to the max tap and employ controlled switching/POW to reduce inrush current. |
Explore related products
What You'll Learn
- Backfeeding a general-purpose transformer is not recommended due to high excitation inrush
- A Delta-Wye transformer should not be connected to the primary system neutral or ground
- A Delta-Wye transformer can be backfed from the Wye side, but with higher inrush current
- A Delta-Wye transformer may have higher voltage drops and higher neutral current
- A Yd transformer may be used to avoid issues with power flow
Backfeeding a general-purpose transformer is not recommended due to high excitation inrush
The high excitation inrush in a general-purpose transformer occurs due to the magnetization of the core from the inside out. This results in lower than expected output voltage and can cause significant coordination issues with breakers or fuses. The inrush current can be up to 10 to 12 times the FLA, leading to difficulties in maintaining compliance with the National Electrical Code.
Additionally, backfeeding a transformer can result in higher inrush current, high neutral current, and a higher voltage drop on the lower voltage side. This can lead to voltage dip issues, particularly in tertiary windings, which can cause voltage dips in the distribution system. It is crucial to address these issues to ensure the safe and efficient operation of the transformer.
To mitigate the challenges posed by backfeeding, certain precautions and solutions can be implemented. For instance, energizing with a full winding by increasing to the max tap and employing controlled switching techniques can help reduce inrush current. However, it is generally recommended to consult with electrical professionals and follow manufacturer guidelines to determine the most suitable approach for a specific transformer.
While backfeeding is not recommended for general-purpose transformers, it is essential to note that some manufacturers, such as Square D, do not explicitly forbid the practice for their low voltage dry type distribution transformers. They emphasize the importance of labelling their transformer terminals as high voltage (H's) or low voltage (X's) instead of primary or secondary. However, they still advise against backfeeding due to the challenges posed by high inrush currents and upstream protection tripping.
