The electrical length of a test fixture is an important factor in impedance measurements. The Keysight E5061B is a network analyser that can be used to measure impedance. To measure the electrical length of a fixture using the E5061B, you will need to connect the 16196A test fixture to the terminal adapter and set the electrical length. This involves turning the adapter's 7-mm connector in the counterclockwise direction and screwing the connection sleeve in fully. Once the test fixture is connected, you can set the open and short states and perform the necessary calibrations. Finally, you can set the compensation to DONE to save the performed fixture compensation and turn it on.
Explore related products
What You'll Learn
Connect the 16196A test fixture to the terminal adapter
To connect the 16196A test fixture to the terminal adapter, follow these steps:
Firstly, ensure you have the correct adapter that fits the measuring instrument. Turn the adapter's 7-mm connector in a counterclockwise direction when viewed from above. Fully screw in the connection sleeve.
The next step is to align the test fixture with the adapter. Position the test fixture gently so that it aligns with the adapter's mount post and 7-mm connector. Once aligned, turn the adapter's 7-mm connector counterclockwise to connect the bottom of the test fixture to the connector.
To ensure a firm connection, use a torque wrench (size: 3/4 inch, torque: 12 lb-in, Keysight part number: 8710-1766) to fasten the adapter's 7-mm connector.
By following these steps, you will securely connect the 16196A test fixture to the terminal adapter, ensuring a stable and reliable connection for your measurements.
