Harvesting Electricity: Nature's Underground Power Source

The Earth contains a natural charge that can be harnessed to generate electricity. This phenomenon has been explored since the 19th century, with early experiments using metal plates and electrodes to generate electrical currents. The concept of an Earth battery involves utilising the Earth's magnetic field and natural water sources to create a sustainable and inexhaustible power source. By understanding the principles of electron flow and the unique properties of various metals, researchers have discovered methods to extract electricity from the ground. This innovative approach to energy generation offers an exciting prospect for a greener and more affordable future.

Earth batteries

The construction of an earth battery involves placing metal plates or spikes in the ground, with one end of each plate connected to a copper wire above the surface. The plates should be positioned in the direction of a magnetic meridian, with the stronger currents flowing from south to north. The plates are not significantly chemically corroded, even when connected by a wire for an extended period. However, the soil may eventually deplete its electrolyte qualities, requiring replacement to restart the process.

To build a small earth battery, you'll need a cathode, an anode, and a container full of soil or compost. A simple cathode can be a galvanized nail or chicken wire, while an anode can be made from graphite cloth. For a budget of around $500, you can build a larger earth battery to power lights and small electrical appliances. This budget should cover multiple copper spikes, galvanized nails, high-value capacitors, and copper wire.

When constructing a large earth battery, it is recommended to install them as line batteries with pairs of zinc and copper spike electrodes planted 5 to 6 feet apart. This creates a series of 'batteries' that draw ions from the earth. The electrodes are then connected to a copper wire, which can be hooked up to your home's lighting system circuit.

Metal plates

An earth battery consists of a pair of electrodes made from two dissimilar metals, such as zinc and copper, or iron and copper, which are buried in the soil or immersed in the sea. The soil acts as an electrolyte in a voltaic cell, and the device acts as a primary cell. The two plates are connected above ground by a wire, with the wire exhibiting as little resistance as possible. The plates must be placed in the direction of a magnetic meridian, with the plate made from the metal that is higher up in the electropotential series placed at the southern end, and the other plate at the northern end.

The current produced is highest when the two metals are most widely separated from each other in the electropotential series. This is because the soil separates the plates, forcing the free electrons to travel through the wire that connects the two metals. The electrodes are not significantly chemically corroded, even when they are in earth saturated with water, and are connected by a wire for a long time. However, eventually, the dirt would become depleted of its electrolyte qualities, requiring the soil to be replaced to restart the process.

The voltage level can be increased by joining several earth battery cells in series, similar to a commercial lead-acid battery. The load current can be increased by connecting earth cells in parallel. The source current capacities can also be increased by adding to the surface areas of the electrodes, although the voltage of a single cell remains constant regardless of the electrode size.

Microbial fuel cells

The first MFCs were demonstrated in the early 20th century, using a mediator: a chemical that transfers electrons from the bacteria in the cell to the anode. Unmediated MFCs emerged in the 1970s; in this type, the bacteria have electrochemically active redox proteins on their outer membrane that can transfer electrons directly to the anode.

In terms of construction, MFCs are made using either a bioanode and/or a biocathode. The electrons produced during oxidation are transferred directly to an electrode or a redox mediator species, and the electron flux is moved to the cathode. The charge balance of the system is maintained by ionic movement inside the cell, usually across an ionic membrane. Most MFCs use an organic electron donor that is oxidized to produce CO2, protons, and electrons. The cathode reaction typically uses oxygen as an electron acceptor, but other acceptors include metal recovery by reduction, water to hydrogen, nitrate reduction, and sulfate reduction.

MFCs are particularly useful for power generation applications that require low power but where replacing batteries may be impractical, such as wireless sensor networks. They are also useful for wastewater treatment, as the bacteria simultaneously consume organic material and clean the water. While MFCs will likely never replace a centralized treatment facility, they are ideal for industrial pre-treatment of challenging, low-volume wastewater, such as high-organic concentration streams from food and beverage manufacturing.

Electrodes

An electrode is an electrical conductor used to make contact with a nonmetallic part of a circuit, such as a semiconductor, an electrolyte, a vacuum, or a gas. They are essential parts of any battery and can be referred to as either a cathode or an anode depending on the direction of the electric current.

The physical properties of electrodes are important, including their electrical resistivity, specific heat capacity, electrode potential, and hardness. These properties influence the efficiency of electrochemical cells, including the self-discharge time, discharge voltage, and cycle performance.

In a battery, the anode is the negative electrode, and the cathode is the positive electrode. The anode loses electrons through a process known as oxidation, while the cathode gains electrons through reduction. This flow of electrons from the anode to the cathode creates an electric current.

Different types of cells use electrodes in different ways. A battery, or galvanic cell, generates electricity from spontaneous chemical reactions. In contrast, an electrolysis cell, or electrolytic cell, uses electricity to force non-spontaneous chemical reactions to occur. In an electrolysis cell, the cathode becomes the negative electrode, and the anode becomes the positive electrode, causing electrons to flow in the opposite direction compared to a battery.

Telluric currents

Earth batteries, which have been used since the 1840s, tap into the low-voltage current of telluric currents. These batteries can be used as an alternative power source as they can be charged naturally in the presence of water, providing inexhaustible electricity.
