Electrical Sockets In Drawers: A Step-By-Step Guide

Keeping your living or working space organised and aesthetically pleasing can be challenging, especially with the number of electronic devices and their chargers that need to be plugged in. A solution to this is installing electrical sockets in drawers, which can be done as a DIY project or with the help of an electrician. This allows you to charge your devices while keeping them stored away and out of sight. There are various options available, such as the Docking Drawer Blade Duo, which provides both charging and powering capabilities in one solution.

Choose a drawer near an existing outlet

When it comes to installing an electrical socket in a drawer, it's important to consider the proximity to an existing power source. Choosing a drawer near an existing outlet is a practical and convenient approach. This way, you can minimise the need for extensive wiring and electrical work.

By selecting a drawer close to an outlet, you can simply connect the new socket to the existing power source with ease. This makes the installation process more straightforward and cost-effective. It's a good idea to opt for a drawer that is easily accessible and located in an area where you frequently use electronic devices. For example, a kitchen drawer near an appliance charging station or a bathroom vanity drawer for hair appliances can be ideal choices.

If you're considering adding an electrical socket to a drawer, it's worth taking the time to survey your space and identify the nearest power outlets. This will help you make an informed decision about which drawer to choose for your new electrical socket. Remember to consider the length of the power cord and any potential safety hazards that may arise with longer cords.

Additionally, by choosing a drawer near an existing outlet, you can reduce the amount of electrical work required. This can be a safer option, especially if you're not an experienced electrician. It's always important to prioritise safety when working with electrical installations, so consulting a professional for guidance or opting for a nearby outlet is a wise decision.

Overall, selecting a drawer near an existing outlet is a practical, convenient, and safe approach when installing electrical sockets in drawers. It simplifies the installation process, reduces costs, and ensures a safer working environment. By taking the time to plan and make thoughtful choices, you can enhance the functionality and aesthetics of your space while keeping safety at the forefront.

Remove the drawer and cut a hole in the back

To install an electrical outlet in a drawer, you must first remove the drawer from the cabinet. Once the drawer is out, you need to cut a hole in the back of the drawer to make space for the outlet. This can be done by using a template to trace the cutout space. Docking Drawer provides a template for cutting the exact size hole needed for your outlet box. Align the template with the centre of the drawer and drill holes in the four corners as marked. Then, use a jigsaw to cut out the rectangle for the outlet.

If you are building your drawers from scratch, you can cut holes in the back of the cabinets where there are outlets on the wall. This way, you will have access to a power source. If there isn't an electrical outlet accessible, you will need to hire an electrician to connect to a power source and ensure it meets electrical safety standards.

Another way to create space for the outlet is to inset the back of the drawer. Simply reattach the back of the drawer 2 inches inside to give the outlet room with the drawer closed. After the back of the drawer is reinstalled, you can install the electrical outlet.

Install a Docking Drawer Blade Duo

Installing a Docking Drawer Blade Duo is a simple process that can help you organise your space and reduce clutter. The Blade Duo outlets are designed to fit any drawer type, including shallow, tall, narrow, and vertical drawers. Here is a step-by-step guide to installing a Docking Drawer Blade Duo:

Step 1: Choose the Right Drawer

First, decide which drawer you want to install the electrical outlet in. It is best to choose a drawer that is already close to an existing outlet. This will make it easier to connect to a power source.

Step 2: Prepare the Drawer

Remove the drawer from the cabinet. If your drawer does not have enough space for the electrical outlet, you may need to inset the back of the drawer to create more room. You can do this by reattaching the back of the drawer further inside, giving the outlet and its arm sufficient space.

Step 3: Cut the Hole

The Docking Drawer Blade Duo kit comes with a template for cutting the exact size hole needed for the outlet box. Align the template with the centre of the drawer and drill holes in the four corners as marked. Then, use a jigsaw to cut out the rectangle for the outlet.

Step 4: Install the Outlet

Slide the arm of the Docking Drawer Blade Duo into the cut-out space, from the inside of the drawer to the outside. Use the screws provided with the kit to secure the outlet in place. The Blade Duo only requires seven screws for installation, which are included in the package.

Step 5: Connect to Power

The Docking Drawer Blade Duo has a 4.5-foot cord that plugs into any in-cabinet outlet. Ensure that the outlet you are using is up to electrical code and has been installed by a certified electrician if necessary.

Step 6: Test and Enjoy

Once the outlet is securely installed and connected to power, you can test it out by plugging in your devices and charging them in your newly organised drawer!

The Docking Drawer Blade Duo is a convenient and safe way to keep your devices charged while reducing countertop clutter. With its interchangeable design and simple installation process, it is a great option for creating a functional and tidy space.

Secure the power strip to prevent movement

To secure the power strip to prevent movement, you can use a variety of tools and methods.

Firstly, it is important to ensure that the power strip is compatible with your drawer setup and has the correct number and type of outlets for your devices. You should also consider factors like proximity to devices, outlet accessibility, and drawer movement.

One method to secure the power strip is to use mounting brackets or adhesive pads, which are often provided with the power strip. This allows you to attach the power strip to the back or sides of the drawer, keeping it secure and out of sight. For height-adjustable desks, ensure the mounting solution accommodates the desk's movement without straining the cords.

Alternatively, you can use cable management tools such as adhesive clips, trays, or sleeves to group and secure wires, ensuring they don't get tangled or damaged by the drawer's movement.

If you're installing a Docking Drawer outlet, it comes with screws to secure the outlet to the back of the drawer and the back of the cabinet. This method ensures the power strip remains secure and doesn't move when the drawer is opened or closed.

By following these methods, you can effectively secure the power strip in your drawer, preventing movement and ensuring a safe and functional setup.

De-energise the outlet when the drawer is closed

De-energising the outlet when the drawer is closed is a safety feature that is available for in-drawer electrical outlets. This feature is not mandatory in the US, but it is in Canada.

One way to ensure that the outlet is de-energised when the drawer is closed is to install a thermal breaker, which cuts power if the temperature in the drawer gets too high. This is a safety feature that helps prevent fires in case something like a curling iron is left on and then placed in the drawer.

Another option is to use a Docking Drawer outlet with a Blade Limit Switch. This switch is attached to the rear mounting bracket of the outlet. When the drawer is open, the switch is depressed, turning the outlet on. When the drawer is closed, the switch expands, triggering the outlet to de-energise. This option also allows you to adjust the switch so that the outlet de-energises at your preferred position of the drawer.

If you are installing an in-drawer outlet, it is important to check the electrical code requirements in your country or region. For example, in Canada, there is an optional interlock box that can be used to de-energise the outlet when the drawer is closed.
