Electrical noise is a common issue in industrial facilities, and it can have detrimental effects on the functionality, performance, accuracy, and consistency of circuits. Noise can arise from either external or internal sources, and it refers to any undesirable signal in a circuit, such as powerline hum, shot noise, atmospheric noise, EMI from switching power supplies, and radio transmitters. To reduce noise in electrical circuits, various methods can be employed, including the use of decoupling capacitors, filters, and grounding techniques. For example, establishing a ground plane can help minimize electrical noise by providing a zero-potential reference. Additionally, anti-aliasing filters can remove noise above a certain frequency, and digital filters can be added to software to filter out lower-frequency noise. Other strategies include using a low-pass filter, which is a combination of a resistor and a capacitor, and employing a CLC-style pi filter or a low-noise regulator to the power supply output.
Characteristics and Values of Reducing Noise in Electrical Circuits
| Characteristics | Values |
|---|---|
| Establish a ground plane | All circuits within a system have the same reference potential for comparing different signals and voltages |
| Utilize anti-aliasing filters | Remove noise at frequencies above the filter cutoff frequency |
| Use digital filters | Filter out noise at frequencies lower than the Nyquist frequency |
| Use decoupling capacitors | Large decoupling capacitors ranging from 0.1uf to 10uf |
| Use surface-mount capacitors | Have low ESL and ESR |
| Use LC or RC filters | Reduce noise in conjunction with an LDO |
| Use a low-pass filter | Allow quick voltage changes to stop before the controller while passing slower deliberate changes to the input terminal |
| Use a CLC-style pi filter | May be effective in reducing noise |
| Use a different power supply | Sharing a common ground can help reduce noise |
Explore related products
What You'll Learn
Use decoupling capacitors, filters and shielding
One of the ways to reduce noise in electrical circuits is to use decoupling capacitors, filters, and shielding.
Decoupling Capacitors
Decoupling capacitors, also known as bypass capacitors, are used to mitigate high-frequency noise signals and reduce power ripples. They provide high transient currents to an Integrated Circuit (IC) and help maintain stable voltage levels. These capacitors are placed near the power pins of an IC to ensure that voltage variations remain within the device's tolerance range. For low-impedance shunting, a single electrolytic capacitor is sufficient, but for signal stabilization, two different types of capacitors are required. Decoupling capacitors are also used to isolate or decouple two circuits, separating AC signals from DC signals or vice versa.
Filters
Filters are used to remove unwanted parts of a signal, such as blocking undesirable frequencies near a radio receiver to reduce radio frequency interference. There are different types of filters, including low-pass, high-pass, band-pass, and band-stop filters, each designed to affect specific frequency ranges. For example, low-pass filters block high frequencies while allowing low frequencies to pass through the circuit. Anti-aliasing filters, a type of low-pass filter, are used in analog-to-digital conversion to condition the analog signal. Capacitors can be used in band-stop circuits to protect sensitive electronics from harmonics in the power supply.
Shielding
Shielding is another effective method to minimize noise in electrical circuits. Electric fields are relatively easier to shield than magnetic fields, and the use of shielding at one or more points can disrupt electrical fields. To shield against magnetic fields, the key is to reduce the loop area by using a twisted pair or returning the current through the shielding. Grounded shielding is typically used above the cut frequency to prevent radiation on a conductor. Additionally, adequate shielding can act as a Faraday cage, providing protection from electromagnetic interference (EMI) and reducing operational costs and problems.
