Replacing an electric awning on a camper or RV is a challenging task that can be done by yourself or with the help of a friend or two, but it may be safer to contact a professional for assistance. The process involves removing the old awning, finding a suitable replacement, preparing for installation, and properly securing the new awning. Before beginning, it is important to measure the size of the original awning to determine the required replacement length and choose the right type of fabric.
| Characteristics | Values |
|---|---|
| Difficulty | Replacing an electric awning on a camper is a challenging task that requires multiple people and can be hazardous. |
| Required Tools | Power drill, screwdriver, socket set, safety gear, ladder, electric drill, cordless drill, bolt extractor, flat blade screwdriver, pop riveter, vice grips. |
| Steps | Measure the awning, remove the old awning, purchase a replacement, prep for installation, secure the new awning. |
| Maintenance | Regularly clean with mild soap and water or a commercial cleaner, inspect the arms and fasteners for rust and wear and tear. |
Explore related products
What You'll Learn
Measure the awning to determine the replacement length
Measuring your current awning is the best way to determine the replacement length. This is a simple but often confused process.
First, measure the size of your original awning from awning arm to arm. Measure from the centre of the forward arm to the centre of the rear arm. This is the most common way to measure an awning, as required by awning manufacturers such as Carefree, Dometic, A&E, Solera, Velarium, and Airexcel.
The replacement fabric will usually be 9 to 12 inches shorter than the awning measurement. So, if the measurement of the distance between the centre lines of the arms is 16 feet, then you will need to order a 16-foot awning fabric. For a 16-foot awning, the actual width of the fabric is between 15’1″ and 15’3″.
Before purchasing a replacement awning fabric, you need to make sure your awning arms have enough extension. You can do this by measuring the full extent of the awning replacement fabric, which is approximately 94-96″.
Updating Electric Log Books: A Simple Guide to LED Maintenance
You may want to see also
Explore related products
Remove the old awning
Removing the old awning from your camper is a tricky task that requires careful attention. It is a two-person job, at a minimum, and it is recommended that you have a few extra pairs of hands to make the process safer and more efficient. Before you begin, park your camper on a flat surface and engage the parking brake. Turn off any connected power sources if your awning is electric. Lay a padded surface or tarp beneath the awning to catch loose screws and protect hardware during removal.
First, remove the two small screws that prevent the fabric from sliding in the track. There should be one screw on each end of the awning, attached to the camper by a long, horizontal metal plate. These can be removed with an electric drill or a screwdriver. Next, pop the awning arms out of their brackets by pulling them outward and away from the camper. Extend them until they are touching the ground. Pull the bottom of the awning arms down. On some models, you may need to pull them upward against the camper.
Roll the awning out about one foot from the camper. Start by flipping the control lever on the right side of the roller tube as if you are preparing to fully extend the awning. Now, remove the roller tube. Get two people to hold the awning 3 to 4 inches off the ground. Pull the awning tube out of the track gently.
Finally, remove the main bolts that hold the top of the awning to the side of the camper. There should be two bolts on each side of the awning, four in total. Use a cordless drill and bolt extractor tip that matches the size of your awning's bolts to remove each one.
Drilling Roofs for Electric Service: A Step-by-Step Guide
You may want to see also
Explore related products
Prepare the installation
Preparing to install a new electric awning on your camper is a challenging task that requires careful planning and execution. Here are the essential steps to help you prepare for the installation process:
Measurements and Compatibility
First, you need to measure the size of your original awning to determine the required replacement awning length. Measure from the centre of one mounting arm to the centre of the other, as this will give you the accurate size for your new awning. If you plan to reuse any mechanical components, also measure the projection (how far the awning extends) and the diameter of the roller tube.
Choose the Right Replacement Awning
Select a replacement awning that is compatible with your camper's make and model. Consider factors such as fabric type, size, and intended use. Decide if you prefer a manual or electric awning, and whether you need features like water resistance or UV protection.
Gather Tools and Assistance
Before beginning the installation, ensure you have the necessary tools on hand. Basic tools include a power drill, screwdriver, socket set, and safety gear. You may also need a ladder and a tarp or padded surface to lay underneath the awning during the installation. It is recommended to have at least one assistant to help with holding the awning and ensuring a safe process.
Prepare the Camper
Park your camper on a flat surface and engage the parking brake. Disconnect any power sources if your awning is motorized. Place a tarp or padded surface beneath the awning to catch loose parts and protect the camper during the installation process.
Remove the Old Awning
Before installing the new electric awning, you must carefully remove the old one. This involves unscrewing or cutting away the fabric, removing the roller tube, and detaching the awning arms from their brackets. Ensure you follow the specific instructions provided with your camper and awning models.
With these preparatory steps completed, you will be ready to begin the installation of your new electric awning, following the manufacturer's instructions and taking care to work safely and efficiently.
Green Energy: Batteries vs. Electricity
You may want to see also
Explore related products
Secure the new awning to the camper's substructure
Securing a new awning to your camper's substructure is a tricky but rewarding task. It is important to follow the general installation instructions that come with your kit, but here are some extra tips to help you secure your new awning.
Firstly, ensure you have the right tools for the job. You will need a power drill, screwdriver, socket set, and safety gear as a basic minimum. It is also recommended to have a ladder and a friend to help hold the awning. Before you begin, park your camper on a flat surface and engage the parking brake. Turn off any connected power sources if your awning is motorized.
Next, you will need to prepare the awning rail extrusion. Place butyl tape on the back of the awning rail extrusion and install it so it is perfectly level across the top of your camper. Now you are ready to secure the new awning. Extend the awning and secure the head assemblies on each side. Use zip ties to secure them. Then, remove the polycord screw on both sides of the awning assembly. This screw should be about 1” from the awning fabric.
Now, you can safely remove the roller tube. Detach the tube from the head assembly on both ends, feed the fabric tube through the awning rail, and place it on a clean, level surface. You can now install your new fabric. Measure your awning from the inside of each cap and purchase an appropriately-sized replacement fabric. Use high-quality, heavyweight, tight-weave vinyl for the best results. Check the manufacturer's instructions for fabric recommendations.
Finally, reinsert the spring assembly into the end of the roller tube, lining up the rivet holes and the awning control lever with the mark on the side of the tube. Use a pop riveter to replace the rivets in the end cap and securely fasten it to the roller tube.
Exploring the Top Speeds of E200 Electric Scooters
You may want to see also
Explore related products
Reattach the awning arms
Reattaching the awning arms is a crucial step in replacing an electric camper awning. It is a challenging task that requires careful attention to detail and a basic understanding of tools and hardware. Here is a comprehensive guide to help you through the process:
Prepare the Awning Arms
Before reattaching the awning arms, ensure they are properly positioned and ready for installation. Extend the awning arms to the ground or, in some models, upward against the camper. This step ensures stability and ease of access during the reattachment process.
Remove Old Fabric
If you are replacing the awning fabric, carefully remove the old fabric from the roller tube. This process may vary depending on the specific design of your awning. Typically, it involves removing screws, spreading the track, and gently pulling out the fabric. Refer to your awning's manual or seek guidance from a professional if needed.
Reattach the Right Awning Arm
Once the fabric is removed, focus on the right awning arm. Remove the protective tape from the right bracket, and snap the support arm into place. Ensure it is securely attached and aligned correctly with the roller tube.
Reinsert the Spring Assembly
Line up the awning control lever with the mark on the side of the roller tube. Reinsert the spring assembly into the end of the tube, making sure the rivet holes line up. Use a pop riveter to replace the rivets securely.
Retighten the Spring Assembly
To retighten the spring assembly, attach vice grips to the roller tube bracket. Click the awning control lever to the roll-down position, then rotate the spring counterclockwise. Ensure you rotate it the same number of times you did when initially removing the spring. Keep a firm grip on the vice grips during this process.
Finalize Reattachment
With the right awning arm securely in place and the spring assembly tightened, perform a final check. Ensure all components are securely fastened and aligned correctly. Refer to your awning's manual for any specific instructions or additional steps required for your particular model.
Remember, replacing an electric awning on a camper can be a challenging task. If you encounter difficulties or feel uncomfortable with any part of the process, don't hesitate to seek professional assistance.
Easy Guide: Connecting Electric VIS DP100 FSA
You may want to see also
Frequently asked questions
Replacing an electric awning is a challenging DIY task that requires careful attention. First, you need to remove the old awning, which involves unscrewing and detaching various components. Then, you must purchase a suitable replacement awning, ensuring it is the correct size and type for your camper van. Finally, you can install the new awning by following the manufacturer's instructions and taking the necessary safety precautions.
Replacing an electric awning typically requires tools such as a power drill, screwdriver, socket set, and safety gear. You may also need a ladder and an extra pair of hands to help hold the awning safely.
Removing the old electric awning involves several steps:
- Unscrew and remove the fabric by detaching it from the track or rail.
- Pop the awning arms out of their brackets and extend them to the ground.
- Remove the main bolts holding the top of the awning to the camper van.
- Carefully lift or slide out the old awning.
When choosing a replacement electric awning, it is important to consider factors such as fabric type, size, durability, UV resistance, water resistance, and opacity. Measure the size of your original awning to ensure a perfect fit, and select a high-quality, heavy-duty fabric that can withstand wear and tear.
Yes, if only the fabric of your electric awning is damaged or worn out, you may only need to replace the fabric. Check with your awning manufacturer to ensure you purchase the correct type of fabric. Measure the size of your awning accurately to get a perfectly sized replacement fabric.
