Electric fencing is an effective way to contain pigs, despite some misconceptions. With the right training and equipment, pigs can be successfully raised using electric fencing. This method offers several advantages, including portability and relatively lower costs compared to traditional fencing solutions. The key to success is early and proper training, which should begin when piglets are around 10-30 pounds and have started exploring their surroundings. It is important to note that the fence should be hot and the ground strong, with a minimum of 2000 volts, to ensure the piglets learn to respect the fence. Additionally, the height and spacing of the wires are critical, with the lowest wire starting 6 inches or less from the ground and subsequent wires spaced closely and evenly up to the height of the pig's nose. For those with large fencing systems or frequent storms, lightning and surge protection is recommended to avoid damaging the farm's electrical supply.
| Characteristics | Values |
|---|---|
| Fence type | Electric |
| Pig type | Piglets, adult pigs |
| Fence wires | Should be close to the ground |
| Pig intelligence | Pigs are intelligent and learn quickly to respect and avoid an electric fence |
| Pig rooting | The lowest fence wire should start 6 inches or less from the ground |
| Wire spacing | Wires should be closely spaced at even intervals up to the height of the pig's nose |
| Minimum number of strands | 3 strands |
| Minimum fence height | 24 inches |
| Fence charger | Zareba® fence charger that maintains a minimum of 2,000 volts on the fence line |
| Soil type | In dry areas, use HogNet® 10/24/12 |
| Fence protection | Install lightning protection and surge protection to avoid blowing your farm's electrics |
| Energizer type | Solid state livestock energizer |
| Pig behaviour | If a pig escapes and cannot be trained, move, sell, or eat it |
Explore related products
What You'll Learn
Fence wire placement
When installing an electric fence for pigs, it is important to consider the height and spacing of the fence wires. The lowest wire should be placed 6 inches or less from the ground to prevent pigs from rooting. The subsequent wires should be spaced closely and evenly up to the height of the pig's nose, with intervals such as 8 inches and 10 inches. It is recommended to have at least three strands of wire for effective containment, with the fence height reaching a minimum of 24 inches. Proper wire spacing is crucial, as pigs may push into the fence instead of pulling out if they receive a shock behind their eyes.
For piglets, the wires should be spaced closer together and lower to the ground. A training pen can be constructed using four hog panels and two strands of electric wire with 6-inch insulators to introduce piglets to the electric fence. It is recommended to use a minimum of 2000 volts for both adult pigs and piglets.
The type of fencing material is also an important consideration. Smooth fiberglass rods with adjustable plastic insulators offer flexibility in adjusting the height of the wire based on the elevation and size of the pigs. Corner T-posts with plastic insulators add strength and allow the wire to be pulled tight. Alternatively, step-in-style fencing offers predetermined slots for the fencing line but lacks the adjustability of the smooth rod system.
To ensure a strong and effective electric fence, a low-impedance charger is recommended, especially in areas with weeds or mud, which can insulate pigs from electric shock. For larger fencing systems or areas prone to storms, consider installing lightning and surge protection to safeguard your farm's electrical system. Additionally, a solid-state livestock energizer can provide a constant electrical current, reducing the chance of pigs jumping through the fence.
Resetting Your GE Fridge: A Quick Guide
You may want to see also
Explore related products
Piglet training
Training piglets to respect an electric fence is an important step in ensuring they are easily contained. It is recommended to start training when they are around 10-30 pounds.
The first step is to build a small pen using four hog panels to form a square. Inside this pen, run two strands of electric wire using 6-inch insulators from the panels. The height of the wire is critical to the containment of piglets, so ensure the lowest wire is no more than 6 inches from the ground, with the next wire at snout height. This setup creates a safe space for the piglets to learn about the electric fence without being surrounded by it.
After setting up the pen, place the piglets' food, water, and shelter inside. Observe their reactions to the electric wires. Some piglets may quickly understand the nature of the electric fence, while others may require a few shocks before they learn to respect it. It usually takes about a week for piglets to grasp the concept.
Once the piglets have been trained in the small pen, you can repeat the test in a different corner or section off a corner in a larger area. This step ensures that the piglets truly understand that they need to stay away from the electric fence. You can then start moving them to different areas, such as your woods, using your three-strand setup without any perimeter fence.
It is important to note that a strong and hot electric fence is crucial for effective training. A low-impedance fence charger is recommended to overcome weeds and ensure a strong current. Additionally, make sure the fence has at least 2,000 volts, and for shorter fences, a minimum of 0.5 joules is sufficient.
Exploring Jetson Electric Scooters: Unlocking Their True Speed Potential
You may want to see also
Explore related products
Fence type
The type of fencing you choose for your pigs will depend on several factors, including the size of your pigs, the terrain, and the frequency of storms in your area.
For smaller pigs, a portable electric fence with three or more strands of wire is recommended. The lowest wire should be placed 2-6 inches from the ground, with the next wires spaced closely and evenly up to the height of the pig's nose. This type of fencing is relatively inexpensive and can be easily moved to different grazing areas. However, it is important to ensure proper wire spacing to prevent pigs from getting their heads stuck between the wires.
For larger pigs, a permanent fencing solution like wire mesh or wooden rails may be more suitable. This type of fencing provides a physical barrier that can help contain stronger and more aggressive pigs. However, it is more expensive and time-consuming to set up and disassemble.
Another option is electro-netting, which is effective for containing pigs in moist areas with wet or dry soils. However, the electric current in electro-netting can deplete as the surface area increases, creating weak points in the fencing.
If you live in an area with frequent storms, consider installing lightning and surge protection for your electric fence to prevent damage to your farm's electrical system.
Additionally, the type of energizer you choose is important. Solid-state livestock energizers provide a constant electrical current, giving pigs less opportunity to jump through the fence.
Neurons' Electrical Voltage: Powering the Brain's Complex Network
You may want to see also
Explore related products
Voltage and grounding
When it comes to electric fencing for pigs, voltage and grounding are critical factors in ensuring the fence's effectiveness and safety. Here are some detailed instructions and considerations for these aspects:
Voltage Requirements:
- It is recommended to maintain a minimum of 2,000 volts on the fence line to safely contain pigs. This ensures that they receive a sufficient shock to deter them from crossing the fence.
- For piglets, a minimum voltage of 3.5 to 4 volts is necessary. However, it's important to note that the success of the fence also depends on the joules delivered, not just the voltage.
- To prevent pigs from running or jumping through the fence, consider using a solid-state livestock energizer that provides a constant electrical current. This eliminates the window of opportunity that slow electrical pulses may create.
- If you have a large fencing system or live in an area with frequent storms, consider installing lightning and surge protection to safeguard your farm's electrical system.
Grounding Instructions:
- Achieving a strong ground is crucial for the electric fence's effectiveness. Ensure that the ground connection is secure and has low electrical resistance.
- For piglets, it's important to wait until they are around one to two weeks old before introducing them to the electric fence. Before this age, they may not have enough weight to properly ground themselves and complete the circuit.
- When training piglets, create a small pen with hog panels and electric wires. Observe their reactions and repeat the test in different corners to ensure they identify the fence as a barrier.
- For adult pigs, ensure proper grounding by starting the lowest fence wire no more than 6 inches from the ground. Space the subsequent wires at even intervals up to the height of the pig's nose (e.g., 8 inches, 10 inches, etc.).
- To overcome insulation caused by mud, which can prevent electric shock, use a low-impedance fence charger.
Energy-Intensive Appliances: What's Draining Your Power?
You may want to see also
Explore related products
Safety considerations
Firstly, the fence design should be tailored to the pigs' size and age. Piglets require wires spaced closer together and lower to the ground than adult pigs. A three-strand fence at 4, 8, and 12 to 16 inches above the ground will contain pigs of various sizes. The lowest wire should be 6 inches or less from the ground, with the next wires closely spaced at even intervals up to the height of the pig's nose.
Secondly, proper wire spacing is crucial to prevent pigs from getting their heads between the wires and receiving a shock behind their eyes, which can cause them to push into the fence. A minimum of three strands of wire is recommended, with a fence height of at least 24 inches. Additionally, ensure that one of the wires is at the animal's shoulder height.
Thirdly, the type of wire used is important. Poly wire is superior to steel wire as it is easy to set up, doesn't kink, stays tight, and its colouring makes it easy to spot.
Next, the electric charge must be strong enough to deter the pigs. A minimum of 2,000 volts is recommended for effective containment. A low-impedance fence charger is also advised to overcome weeds and penetrate mud, which can insulate pigs from the electric shock.
Furthermore, consider the grounding of the fence. A strong ground is essential, as most fencing problems arise from weak grounding. Copper grounding rods are the most conductive but also the most expensive.
Lastly, always use insulated rubber or plastic gate handles to complete the circuit. These are vital for rotational grazing setups, allowing easy movement of pigs between paddocks without dismantling the entire fence.
By following these safety considerations and guidelines, you can effectively and safely contain pigs using electric fencing.
Drying Your Cannon Electric Blanket: Quick Tips
You may want to see also
Frequently asked questions
There are two main types of electric fencing for pigs: step-in style with predetermined slots to run your fencing line through, or smooth rods that require plastic insulators to be added. The step-in style is convenient as it doesn't require additional insulators, but it's not suitable for land with elevation changes. Smooth fiberglass rods with plastic insulators are adjustable, allowing you to pick the height you need depending on the elevation and size of the pig.
It's important to train piglets to respect an electric fence. Build a small pen with hog panels and run electric wires inside. Observe their behaviour and ensure they understand the boundary. Additionally, proper wire spacing is crucial. The lowest fence wire should start 6 inches or less from the ground, with the next wires closely spaced at even intervals up to the height of the pig's nose. A minimum of three strands of wire is recommended for pigs, with a fence height of at least 24 inches.
Ensure that your electric fence has a strong ground and maintains a minimum of 2,000 volts to effectively contain pigs. If you live in an area with frequent storms or have a large fencing system, consider installing lightning and surge protection to prevent electrical issues. Mud can insulate pigs from electric shock, so use a low-impedance fence charger to penetrate the mud. Additionally, consider the drawbacks of electro-netting, as the electric current may deplete over a large surface area, creating weak points in your fencing. If your pigs are escaping despite your efforts, consider switching to a permanent fencing solution.
