Electrical drawings are visual representations of electrical systems and wiring for electricians and electrical engineers to reference. They include electrical components such as outlets, fixtures, switches, lighting, fans, and appliances. Electrical drawings are typically shown in 2D and consist of symbols, notes, and schedules. However, the inclusion of conduit routing in electrical drawings is a topic of discussion among professionals. Some argue that conduit routing is unnecessary and increases complexity and costs, while others believe it provides valuable information for contractors and helps avoid field conflicts. The decision to include conduit routing in electrical drawings depends on industry standards, project complexity, and specific client requirements.
| Characteristics | Values |
|---|---|
| Conduit drawings by country | In the US, conduits are shown for shop drawings, usually 20mm and above. In the UK, conduits are only shown for specific details or intentions. In Canada, only junction boxes are shown on contractor as-builts. |
| Conduit drawings by project type | Conduit drawings are more common for complex industrial projects. For residential projects, they are considered unnecessary and a waste of time. |
| Reasons for not drawing conduits | Drawing conduits is time-consuming and expensive, and the exact routing is often modified in the field. Electrical drawings focus on symbols, notes, and schedules, and conduit routing is rarely required for permits. |
| Reasons for drawing conduits | Conduit drawings provide valuable information for contractors, enabling more accurate takeoffs and estimates. They also help avoid field conflicts with other systems, such as duct or piping mains. |
| Conduit drawing practices | Conduit drawings may include conduit size, wire size, and routing information. However, combining wires into shared conduits is handled with caution due to potential code compliance issues. |
| Conduit drawing challenges | Modelling conduits, especially with offset bends, is challenging and may lead to unnecessary questions and issues. |
Explore related products
What You'll Learn
Conduit size and type
When it comes to electrical drawings, conduit size and type are crucial considerations. The conduit size is typically determined by the number and type of conductors or wires that will be routed through it. Stranded wires, for instance, occupy more space due to the tiny air gaps between strands, whereas thicker wires necessitate more room. To ensure compliance with the National Electrical Code (NEC) and prevent issues like wire overheating or violation of NEC rules, it is essential to select the appropriate conduit size.
Conduit sizes are commonly designated by their "trade size," which serves as a standard naming system in the industry rather than an exact measurement. For example, a 1-inch conduit trade size does not equate to a 1-inch inner or outer diameter. Different types of conduits, such as PVC, EMT, RMC, and flexible metal, exhibit variations in wall thickness, resulting in discrepancies in inner space despite sharing the same trade size. Therefore, it is imperative to refer to a conduit size chart or the NEC book to ascertain the precise dimensions and select the appropriate conduit type for the specific application.
The scale employed in electrical plans also influences the depiction of conduit size and type. These plans are often drafted at the same scale as floor plans, with the most common scales being 1⁄4" = 1'-0" (1:50 metric) for small projects and 1⁄8" = 1'-0" (1:100 metric) for large commercial ventures. The scale aids in determining the size, length, and distance of equipment, and it is typically provided adjacent to or below the drawing title. Designers may occasionally enlarge equipment drawings, presenting their respective scales beneath them.
In terms of presenting conduit size and type in electrical drawings, it depends on the construction type, project size, and specific details being conveyed. For instance, in wood and drywall construction, it is common to use "free wire" inside walls, represented by a "circuit home run" in plans. In contrast, commercial or industrial projects tend to include more intricate details. Shop drawings typically exhibit conduits measuring 20mm and above, whereas small conduits under 32mm in diameter are often omitted from design drawings.
Ultimately, the decision to include conduit details in electrical drawings may vary across regions. For instance, in the US, it is not uncommon to encounter extensive arrangements of 4" conduits in underground and overhead runs. In contrast, the UK generally omits conduits from drawings unless they serve a specific purpose or meet a particular size threshold, primarily on site plans.
