A diesel locomotive is a type of railway locomotive that uses a diesel engine as its power source. The most common types of diesel locomotives are diesel-electric and diesel-hydraulic, which differ in how mechanical power is conveyed to the driving wheels. This paragraph will focus on diesel-electric locomotives and how they are started. To start a diesel-electric locomotive, a battery is required to provide the initial power, similar to an automobile. Once the engine is running, an alternator supplies power to the electronics and batteries. The locomotive operates on a nominal 64-volt electrical system, with eight 8-volt batteries each weighing over 300 pounds. The large displacement diesel engine has a slower operating speed than gasoline engines and requires a hybrid setup, where the main engine runs at a constant speed and powers an electrical generator. This generator then sends electrical power to a traction motor at each axle, which powers the wheels and gets the locomotive moving.
| Characteristics | Values |
|---|---|
| First diesel-electric locomotive | Built by Fiat in 1922 |
| First domestically developed Chinese diesel vehicle | Dongfeng DMU, produced in 1958 |
| First diesel-hydraulic locomotive | V 140, built in Germany in 1935 |
| Common diesel locomotive types | Diesel-electric, diesel-hydraulic, diesel-mechanical |
| Diesel locomotive power source | Diesel engine |
| Diesel locomotive engine example | Caterpillar EMD 710 series engine |
| Engine weight | Over 24,000 pounds (10,886 kilograms) |
| Engine speed | Much slower than gasoline engines, maxing out at about 2,100 rpm |
| Transmission system | Mechanical, hydraulic, or electric |
| Diesel-electric locomotive transmission | Electric |
| Diesel fuel tank capacity | 5,500 gallons (20,820 liters) |
| Coolant capacity | 300 gallons (1,135 liters) |
| Engine oil capacity | 250 gallons (946 liters) |
| Electrical system | Nominal 64-volt |
| Number of batteries | 8 |
| Battery weight | Over 300 pounds (136 kilograms) each |
| Wheel traction | Increased by spraying sand using compressed air |
Explore related products
What You'll Learn
The role of the battery
The battery is a crucial component of a diesel-electric locomotive, playing a vital role in starting the engine and maintaining essential functions.
Firstly, the battery provides the electrical power required to start the diesel engine. With a large starter motor, the battery delivers the initial burst of energy to get the engine running. This is similar to the role of a battery in an automobile, where it provides the necessary spark to ignite the fuel and start the engine.
Once the engine is running, the battery's role shifts to powering the locomotive's electronics. This includes providing electricity for lights and controls, especially when the engine is switched off and the alternator is inactive. The locomotive's electronic systems are essential for various functions, including traction control and power management.
The diesel-electric locomotive typically operates on a nominal 64-volt electrical system, requiring eight 8-volt batteries, each weighing over 300 pounds (136 kilograms). These batteries are heavy-duty and designed to withstand the rigours of locomotive operation.
In addition to starting the engine and powering electronics, the batteries in modern diesel-electric locomotives also contribute to traction control. Through electronic systems, the power from the batteries can be directed to the traction motors, enhancing wheel adhesion and reducing slippage. This advanced feature, known as creep control, ensures a smooth and efficient start for the locomotive.
Overall, the battery is an essential component of a diesel-electric locomotive, enabling the engine to start, powering critical electronics, and enhancing operational performance through advanced traction control systems.
Electric Sheep Dreaming of Space-Rock: A Cosmic Odyssey
You may want to see also
Explore related products
The engine's power source
The power source of a diesel-electric locomotive is, as the name suggests, a diesel engine. The engine is large and heavy, weighing over 24,000 pounds (10,886 kilograms). It is a two-stroke, turbocharged engine with a displacement of 710 cubic inches (11.6 litres) per cylinder. This is more than double the size of most of the biggest gasoline V-8 car engines. The engine has a slow operating speed, topping out at about 2,100 rpm.
The diesel engine is coupled with an electrical generator to provide the power needed to pull heavy loads at high speeds. The generator sends electrical power to a traction motor at each axle, which powers the wheels. This hybrid setup allows the diesel engine to run at a constant speed, turning the electrical generator via driveshaft.
The locomotive has a large fuel tank, holding up to 5,500 gallons (20,820 litres) of diesel fuel. It also holds 300 gallons (1,135 litres) of coolant and 250 gallons (946 litres) of engine oil. The locomotive operates on a nominal 64-volt electrical system and has eight 8-volt batteries, each weighing over 300 pounds (136 kilograms). These batteries provide the power needed to start the engine and run the electronics.
Most diesel locomotives use electric transmission and are called "diesel-electric" locomotives. This type of transmission provides traction motors on the axles to give the final drive. Mechanical and hydraulic transmissions are also used, but are more common on multiple unit trains or lighter locomotives.
Electric Propulsion: Understanding the Spin Dynamics
You may want to see also
Explore related products
Transmission systems
Diesel-electric locomotives have revolutionised rail transport by combining the benefits of diesel engine drives and electric systems. Unlike traditional steam locomotives, which require extensive maintenance and fuel, diesel-electric locomotives are more dependable and simpler to maintain. The diesel engine in a diesel-electric locomotive acts as a prime mover, generating electricity rather than directly driving the train's wheels.
Diesel-electric locomotives use a variety of transmission systems, including mechanical, hydraulic, and electric. The most common type of transmission is electric, where the mechanical energy produced by the diesel engine is converted into current for electric traction motors. This system provides greater efficiency and flexibility, as well as reducing wear and tear on mechanical components.
Mechanical transmission, the simplest type, is primarily used in low-power switching locomotives and diesel railcars. In this system, the main drive shaft is coupled to the engine by a fluid coupling, or hydraulic clutch. The engine turns a fan, which drives oil towards a rotating disc, causing the disc to turn and the drive shaft to gradually start. This acts as an automatic clutch, allowing for a smooth locomotive start.
Hydraulic transmission, which gained popularity in Germany, is often used in diesel railcars and multiple-unit train sets. It employs a centrifugal pump or impeller to drive a turbine in a chamber filled with oil or a similar fluid. The pump, powered by the diesel engine, converts engine power to kinetic energy in the oil, which then impinges on the turbine blades. As the blades spin faster, the locomotive accelerates.
Direct-drive transmissions can be quite complex, especially when compared to diesel-electric systems, which simplify the transmission of power to the wheels. A typical locomotive has four or more axles, and a direct-drive diesel locomotive would require a large number of gears to function effectively. By coupling the diesel engine to a generator, this issue is avoided.
Electrical Wiring: Horizontal or Vertical Installation?
You may want to see also
Explore related products
Traction control
Diesel-electric locomotives use a diesel engine to turn an electric generator, which then provides power to the traction motors. These motors are responsible for propelling the locomotive, and their control is a critical aspect of operating a diesel-electric locomotive.
Historically, DC motors were preferred for diesel-electric locomotives due to their ease of control and suitability for railway applications. However, with advancements in power electronics, AC motors have become the standard choice for most new equipment. AC systems offer efficient power distribution along rail lines and allow for speed control using switchgear. Additionally, the advent of power semiconductors has enabled the use of variable frequency drives, providing a wide range of speeds and the ability to use rugged induction motors.
The arrangement of traction motors in diesel-electric locomotives is typically designed to have one motor driving each axle through a gear drive. This setup is known as a "nose-suspended traction motor." However, it presents the challenge of increased unwanted forces on the track due to the unsprung weight of the motor. To address this, some locomotives employ a "Bi-Polar" design with direct-drive motors or utilize frame-mounted motors driving each axle through a quill drive.
The horsepower rating of traction motors in diesel-electric locomotives is crucial. Typically, the horsepower rating of the traction motors is approximately 81% of the prime mover's rating, considering the efficiency of the electrical generator and the traction motors. To prevent damage, traction motors are usually cooled using forced air, water, or dielectric liquid. This is particularly important due to the high power levels involved in their operation.
The Electric Slide's Release: A Year to Remember
You may want to see also
Explore related products
Engine maintenance
Preventive maintenance involves routine inspections and upkeep to avoid breakdowns. This includes daily checks of fluid levels, critical components, and safety compliance, as well as weekly detailed system checks and fluid top-ups. Monitoring the engine's oil pressure, level, and quality is essential for proper lubrication and to safeguard against damage. Regularly inspect the cooling system components, including the radiator, water pump, and hoses, for leaks or blockages to prevent overheating. Conduct thorough electrical checks on the battery, alternator, and wiring to address any issues with the engine's starting and operation.
Corrective maintenance addresses issues as they arise through troubleshooting techniques. This includes identifying and repairing issues with fuel injectors, turbochargers, and air filters. It is important to use high-quality fuel and to regularly inspect and clean the injectors to prevent clogging. Additionally, be mindful of potential electrical issues by checking for proper electrical connections and using diagnostic tools to assess injector performance.
Performance-based maintenance focuses on upgrades and improvements to enhance efficiency. This includes long-term considerations such as implementing emission control systems, traction motor upgrades, and advanced diagnostic tools. Biannual and annual servicing are also important, with biannual servicing involving filter and component replacement, and annual servicing involving extensive system inspections and upgrades.
By implementing a systematic maintenance schedule that incorporates all three types of maintenance, you can ensure optimal performance, longevity, and safety for your diesel-electric locomotive.
Texas Electricity Crisis: Power Back On?
You may want to see also
Frequently asked questions
A diesel locomotive is a type of railway locomotive in which the power source is a diesel engine. The most common type of diesel locomotive is the diesel-electric locomotive, which uses electric transmission, with traction motors provided on the axles to give the final drive.
A diesel-electric locomotive needs a battery to start it, as well as to provide electrical power for lights and controls when the engine is switched off and the alternator is not running. Once the engine is running, an alternator supplies power to the electronics and the batteries.
A diesel-electric locomotive has a giant two-stroke, turbocharged engine and electrical generator, which provide the power needed to pull heavy loads at high speeds. The locomotive also has a fuel tank, coolant, engine oil, and batteries.
