Taking apart a Maytag electric dryer can be done in three stages: removing the door, front panel, and top of the dryer; removing the drum; and finally, removing the back panel to access the rollers. Before starting, it is important to read about the dryer basics and how to make electrical checks with a volt-ohm meter. The process begins by removing the screws on the bottom lip of the front of the dryer, followed by pulling out the bottom to disengage the front from the clips holding it in place. The wires from the door switch can then be removed. From here, parts such as the heater, operating thermostat, and thermal fuses can be checked and repaired.
Explore related products
![[LIFETIME WARRANTY] 3387134 Cycling Thermostat 3392519 Dryer Thermal Fuse 3977393 Thermal Cut-off Switch 3977767 High-limit Thermostat Kit - Compatible with Whirlpool Kenmore Maytag Dryers](https://m.media-amazon.com/images/I/81FYRO8xJjL._AC_UY218_.jpg)
What You'll Learn
Removing the door, front panel and top of the dryer
To remove the door, front panel and top of the dryer, start by removing the screws from the door hinges and from across the door on the other side. You may need to lift the door a little to remove it from the hinges. Set the door aside.
Next, remove the front panel. It is shaped like a football goal post. Grab the thinner upper part, twist the outside part to unclip the top section, then pull the panel towards you and lift it off the bottom clips. Set the front panel aside.
Now, remove the two screws and top clips. This will allow you to lift the top of the dryer a little. Remove the wires from the door switch.
At this point, you can remove the bulkhead. Again, the top must be lifted a little to get the bulkhead off.
Now that the door, front panel and top of the dryer have been removed, you can proceed to the next stage of disassembly.
Choosing the Right Electrical Disconnect Size
You may want to see also
Explore related products
Disconnecting the belt and motor pulley
Accessing the Belt and Motor Pulley:
Before disconnecting the belt, it's essential to gain access to it. This involves removing the front panel of the dryer. Start by removing the two screws on the bottom lip of the front panel. Then, gently pull out the bottom of the front panel to disengage it from the clips holding it in place. Set the front panel aside, being careful not to stretch or damage any wires.
Disconnecting the Belt:
The process of disconnecting the belt from the idler pulley and motor pulley may vary slightly depending on the model of your Maytag dryer. For older models, there may be an access panel at the rear of the dryer where you can loosen the belt from the idler pulley. However, for newer models, this step must be performed from inside the dryer.
Loosen the belt by lifting the top slightly and carefully following the belt's path to avoid any tangles or misalignment. Once the belt is loose, carefully remove it from the idler pulley and motor pulley. It's important to note that the belt may be threaded in a specific way, so take note of how it is positioned for easier reassembly.
Removing the Drum:
After the belt is disconnected, you can proceed to remove the drum. Lift the drum assembly slightly and pull it out from the back of the dryer. This will grant you access to the interior of the dryer cabinet, where you can perform further repairs or replacements.
Safety Precaution: It is recommended to disconnect the power source to the dryer before attempting any disassembly or repairs. Work with gloves and protective eyewear to prevent any injuries or accidents.
Electrical Station Maintenance: A Guide to Saint Paul's System
You may want to see also
Explore related products
![[2025 Upgraded] BlueStars 3977456 WP3977456 Dryer Start Switch for Kenmore, Whirlpool, Maytag, Amana Clothes Dryer, Dryer Push to Start Switch - Replaces AP6009036, PS11742178, EAP11742178, 898073](https://m.media-amazon.com/images/I/71fopBNDINL._AC_UY218_.jpg)
Removing the drum
To remove the drum from your Maytag electric dryer, you'll first need to remove the door, front panel, and top of the dryer. Start by removing the screws from the door hinges and lifting the door off. Then, remove the screws from the front panel and lift that off as well. Next, lift the top of the dryer and remove the bulkhead, being careful to disconnect the door switch wires.
With the bulkhead off, you'll need to disconnect the belt from the idler pulley and motor pulley. This will allow you to remove the drum. Lift the top of the dryer slightly to remove the drum. Once the drum is out, you'll have access to the inside of the dryer cabinet and can perform any necessary repairs or replacements.
If you're having trouble with a squeaking or non-spinning drum, you may need to replace the drive belt. This will require further disassembly to access the internal panel covering the drum. Take a picture of the wires connected to the panel and then carefully disconnect them. There should be two or three wires on the bottom and two on the top. Unscrew the two bolts holding the panel in place and remove it to expose the drum.
At this point, you can grasp the drum and slide it forward off the rollers. Pull off the drive belt and remove the drum from the dryer. If the rollers are binding, you can replace them. Each roller is held by a bolt that can be loosened with a 1/2-inch wrench. Keep in mind that accessing electrical or gas components can be dangerous, so it's recommended to hire a service technician for these types of repairs.
Electric Safari: Open in Snowy Weather?
You may want to see also
Explore related products
![[Newest] 4392067 Dryer Repair Kit and W10837240 Dryer Idler Pulley for Maytag Bravos Whirlpool Duet Kenmore Elite Dryers,with WPW10314173 Drum Roller&661570V Belt&279640 Idler Pulley by TOMOON](https://m.media-amazon.com/images/I/71wJfNcwc0L._AC_UY218_.jpg)
Removing the back panel
To remove the back panel of your Maytag electric dryer, you will first need to remove the door, front panel, and top of the dryer. Start by removing the four screws from the door hinges, two from the top clips, and two from the door hinges. You will then need to lift the door slightly to remove it from the hinges. Set the door aside and remove the wires from the door switch.
Next, you will need to remove the front panel. The front panel is shaped like a football goal post. Grab hold of the thinner upper part and give it a little twist to unclip the top section. Pull the panel towards you and lift it off the bottom clips. Set the front aside.
With the front panel removed, you will now need to remove the two screws and top clips. This will allow you to lift the top of the dryer slightly. From here, you can remove the bulkhead by lifting the top a little and disconnecting the wires from the door switch.
Now that the bulkhead is off, you will need to disconnect the belt from the idler pulley and motor pulley. This will allow you to remove the drum. Lift the drum assembly and pull it out from the back of the dryer. With the drum removed, you will have access to the internal components of the dryer, including the back panel.
Electrical Socket Upgrade: A DIY Guide to Modernizing Your Home
You may want to see also
Explore related products
Accessing and replacing rollers
To access the rollers of a Maytag electric dryer, you will need to disassemble the dryer. Start by unplugging the dryer. If it's a gas dryer, turn off the gas and disconnect the gas hose. Remove the screws from the door hinges and lift the door up slightly to remove it. Set the door aside.
Remove the front panel by twisting the upper part of the panel, which is shaped like a football goal post, and unclipping the top section. Pull the panel towards you and lift it off the bottom clips. Set the front panel aside. Next, remove the screws and top clips, and lift the top of the dryer up slightly.
Now, you need to disconnect the belt from the idler pulley and motor pulley. The belt should be threaded around the idler pulley, and the flat side of the belt should go towards the drum, while the grooved side rides the motor pulley. With the drum removed, you can access the rear rollers.
To remove the old rollers, simply disconnect the belt from the drum and remove any screws or brackets that are securing the rollers. Each roller is held by a bolt that can be loosened with a 1/2-inch wrench. Install the new rollers by reversing these steps.
The Heart's Electrical Secrets: How Does it Work?
You may want to see also
Frequently asked questions
The disassembly process for a Maytag dryer depends on the type of repair required. Typically, the first stage is to remove the door, front panel, and top of the dryer. The next step is to remove the drum, which may require belt replacement. Finally, remove the back panel to access the rollers.
First, remove the two screws on the bottom lip of the front of the dryer. Pull out the bottom of the front panel to disengage it from the clips holding it in place at the top. Then, remove the wires from the door switch.
Before starting any repairs, it is recommended to read about dryer basics and learn how to make electrical checks with a volt-ohm meter. When accessing internal components, it is best to hire a service technician for safety purposes.
