Understanding the difference between line and load wires is essential for electrical safety and functionality. Line wires are those that deliver power from the source to a device, while load wires carry power onwards to other devices further along the circuit. Line wires are typically black, red, or black and red, while load wires are usually white, but this colour-coding system is not standardised. Line wires are always hot, meaning they carry an electrical current, while load wires only conduct when the switch is on. Knowing the difference between the two is vital for electrical work, from installations to troubleshooting and maintenance.
Explore related products
What You'll Learn
Line wires are usually black, load wires are usually white
In the electrical trades, the terms "line" and "load" are shorthand words that refer to electrical wires that deliver power from the source to a device (line) and those that carry power onwards to other devices further along the circuit (load). Line wires are usually black, and load wires are usually white. However, this is not always the case, and the colour system can be confusing as there is no standard colour-coding system.
The line wire is the input to the light switch, and the load wire carries the power from the switch to the light. The line wire is always "hot", meaning it carries an electrical current and is the "supply line" of electrical power. The load wire carries the electricity from some terminal point to the point of use.
Line and load have special meanings when wiring ground-fault circuit interrupter (GFCI) outlets. GFCIs have two pairs of screw terminals for connecting wires: one pair is marked "LINE", and one is marked "LOAD". Connecting to the line terminals only results in the outlet providing GFCI protection only for that outlet. Connecting for the line and load terminals provides GFCI protection for that outlet and other standard outlets located downstream on the same circuit.
It is critical to understand the difference between line and load wires for safety reasons and to avoid electrical mishaps.
