Utility poles, also known as transmission poles, are used to support overhead power lines and carry electricity at varying voltages. These voltages differ depending on whether the power lines are sub-transmission lines, which carry higher voltages between substations, or distribution lines, which carry lower voltages to customers. The voltage of distribution lines can range from 4.6 to 33 kilovolts, while sub-transmission lines can carry voltages of 46 kV, 69 kV, or 115 kV. In some cases, ultra-high-voltage lines can carry voltages above 800 kV. These utility poles are typically made of wood, aluminum alloy, metal, concrete, or composites like fiberglass, and they play a crucial role in transmitting electrical energy over long distances.
| Characteristics | Values |
|---|---|
| Purpose | To support overhead power lines and other utilities such as electrical cables, fibre optic cables, transformers, and street lights. |
| Types | Transmission poles and distribution poles. |
| Transmission Pole Voltages | Ultra-high voltage (UHV) – higher than 800 kV. Some lines are operated at voltages exceeding 765,000 volts. |
| Distribution Pole Voltages | 4.6 kV to 33 kV for distances up to 30 miles. Standard voltages range from 2,400 V to 34,500 V. |
| Materials | Wood, steel, aluminium, concrete, reinforced plastics. |
| Conductor Types | Single-phase AC-power lines, delta systems, grounded-wye systems. |
| Safety Features | Guy-wires, strain insulators, fused cutouts, ground wires. |
| Additional Features | Communication wires (telephone/cable TV), transformers. |
Explore related products
What You'll Learn
- Electric pole lines carry two types of power lines: sub-transmission and distribution
- Sub-transmission lines carry higher voltages between substations
- Distribution lines carry lower voltages to customers
- Voltages in distribution lines range from 2,400 to 34,500 volts
- Pole-mounted transformers reduce high distribution voltages to lower secondary voltages
Electric pole lines carry two types of power lines: sub-transmission and distribution
Sub-transmission lines carry higher-voltage power from regional substations to local substations. They typically carry voltages of 46 kV, 69 kV, or 115 kV and can cover distances of up to 60 miles (100 km). In North America, voltages of 69 kV, 115 kV, and 138 kV are commonly used for sub-transmission. Sub-transmission lines consist of three conductors, labelled "A", "B", and "C", and sometimes include an overhead ground wire (OGW) that acts as a lightning rod, protecting the phase conductors from lightning strikes.
Distribution lines, also known as "feeders", carry power from local substations to customers. These lines generally operate at lower voltages, typically ranging from 4.6 to 33 kilovolts (kV), and cover shorter distances of up to 30 miles (50 km). Distribution lines utilise transformers to step down the voltage to the lower secondary voltage used by customers. This lower voltage is then delivered to the customer's premises through a service drop.
In some cases, due to economic or practical considerations, a distribution line may be mounted under a sub-transmission line on the same pole, a practice known as "underbuild". Telecommunication cables are often found on the same poles as power lines, and these poles are referred to as joint-use poles. The electric power distribution lines are typically positioned above the telecommunication cables for safety reasons.
The voltage levels in sub-transmission and distribution lines are not strictly separated, and their ranges can overlap. As power systems have evolved, the voltages used for transmission have transitioned to sub-transmission, and sub-transmission voltages have become distribution voltages. Efficient long-distance transmission of electricity requires high voltages to minimise losses from strong currents, while local distribution relies on lower voltages.
