There are two primary electrical systems that a building may have: single-phase and three-phase electrical systems. Single-phase electrical systems are used in smaller commercial buildings and residential homes, while three-phase systems are used in larger buildings like schools and industrial buildings. A two-phase system consists of two currents that differ in phase by 90 degrees. However, it has been noted that technically, there is no such thing as a two-phase motor or electrical service, and if one is found, it is used in a special purpose situation and has been outdated for over a hundred years.
Explore related products
What You'll Learn
- Single-phase voltage is derived from a transformer secondary with a neutral in the middle
- Two-phase systems are outdated and were used for smaller commercial buildings
- Three-phase transformers have three primary and three secondary coils
- Two-phase systems have two currents that differ in phase by 90 degrees
- Single-phase systems are used in residential homes
Single-phase voltage is derived from a transformer secondary with a neutral in the middle
In a three-phase transformer, the voltage between any line is called the "line voltage" (VL), while the voltage between any line and the neutral point is called the "phase voltage" (VP). The phase voltage between the neutral point and any one of the line connections is given by the equation VP = 1/√3 × VL. This type of transformer can be connected in a delta or star configuration, with the star configuration being more commonly used in power distribution systems as it allows for a fourth wire to be connected as a neutral point.
In a single-phase transformer, the neutral terminal is derived differently depending on the voltage configuration. For a single-phase transformer with dual 120V secondaries, a 240/120V system with a neutral can be obtained by connecting terminals X2+X3. For a 120V only system, X2+X4 are connected as the neutral terminal, and X1+X3 are connected as the 120V line terminal. Single-phase transformers do not have three-phase Wye secondaries, so they do not have an X0 neutral terminal designation like three-phase transformers.
Single-phase voltage is commonly used in smaller commercial buildings and residential homes, where it is often combined to create higher voltages for larger electrical systems. Despite the name, single-phase voltage does include two phases, typically referred to as A phase and B phase, each with 120 volts. These two phases are not truly separate phases, as they are simply two hot legs taped to opposite ends of the same secondary coil.
