Electrical cable colours are carefully chosen to guide users through electrical systems, ensuring safety, proper installation and clear communication between electricians. Colour coding offers a visual cue to a wire's purpose and potential for danger. The colours of electrical cables vary depending on the region and application. For example, in the UK, the earth wire cable colour is green, the neutral wire cable colour is blue, and the live wire cable colour is brown. In the US, the grounded neutral conductor of a power system is white or grey, while the protective ground is bare, green or green-yellow striped, and hot wires are any other colour.
Characteristics and Values of Electrical Cable Colours
| Characteristics | Values |
|---|---|
| Purpose of Colour Coding | To guide users through the electrical system, indicating a wire's purpose and potential danger |
| Colour Coding Standards | IEC (International Electrotechnical Commission) |
| Protective Ground Wire | Green or Green with Yellow Stripe |
| Neutral Wire | White or Grey, Blue (UK and Europe) |
| Hot/Live Wire | Black, Red (second active), Brown (UK and Europe) |
| Three-Phase Lines | Red, Black, Blue |
| Three-Phase Current Cable Colours | Brown, Black, Grey, Blue, Green-Yellow |
| Permitted Colours for Cables with More Than 5 Cores | Black, Brown, Red, Orange, Yellow, Green, Blue, Violet, Grey, White, Pink, Turquoise |
