Electrical symbols are used to represent electrical components or devices in schematic diagrams or circuit diagrams. These symbols are used to draw electrical circuits and are internationally standardized. Some common electrical symbols include earth electrodes, cells, batteries, resistors, capacitors, antennas, and switches. These symbols can be used to create accurate electrical diagrams, allowing anyone familiar with electrical and electronic circuits to quickly read, understand, and build them.
| Characteristics | Values |
|---|---|
| Purpose | Used for drawing schematic diagrams |
| What they represent | Electrical and electronic components or devices |
| Types | Earth electrodes, cells, batteries, resistors, switches, isolators, circuit breakers, SPST, SPDT, DPST, DPDT, transistors, capacitors, antennas, relays, inductors, diodes, LEDs, TVS diodes, Zener diodes, speakers |
| Variations | May vary from country to country or engineering discipline |
| Standards | IEC 60617 (BS 3939), IEC 61131-3, JIC (Joint Industrial Council), ANSI Y32.2-1975 (IEEE Std 315-1975 or CSA Z99-1975) |
Explore related products
What You'll Learn
Electronic circuit symbols
Electrical and electronic symbols are used to draw schematic diagrams. They represent electrical and electronic components. Electronic symbols are a type of electrical symbol, but they are more specific to electronic components such as transistors, diodes, integrated circuits, and other electronic devices.
There are many standard symbols used to represent specific components in a circuit diagram. Basic electrical symbols include earth electrodes, cells, batteries, resistors, and more. A resistor, for example, is represented by a zigzag line, and a battery is represented by a long, thin rectangle.
Electronic symbols can include a circle, and the pin letters B/C/E and G/D/S are not part of the transistor symbols. For multiple-pole switches, a dotted or dashed line can indicate two or more switches at the same time.
The symbols used can vary depending on the context and discipline. For instance, lighting and power symbols used in architectural drawings may differ from symbols for devices used in electronics.
It is important to learn how to read and understand these symbols, especially if you are a beginner in electronics and electrical planning. Software such as EdrawMax offers libraries and templates to help create diagrams and understand the various symbols and their meanings.
