Electrical plugs under the dashboard of a car can be used for various purposes. They can be used to read diagnostic codes and errors, control the air conditioning, control the cruise control, or even be a part of the wiring for fog lights. In some cases, these plugs may not be connected to anything and may be left over from the manufacturing process. Determining the specific purpose of an electrical plug under the dash often requires knowledge of the car's make, model, and year.
