Electric circuits are closed-loop pathways that allow electrons to flow through them. They are made up of at least two parts: a voltage source, such as a battery, and a conductor, such as a wire. Other components include switches, which can break a circuit by diverting the current, and loads, which are electric components that convert electrical energy into other forms of energy, like light bulbs. Cells, which are devices with positive and negative terminals, can also be used as power sources. These basic components can be combined in different ways to create series or parallel circuits, allowing for a variety of applications, from lighting to electronic devices.
Explore related products
What You'll Learn
Sources of power: cells, batteries, and voltage
The term "battery" was first used by Benjamin Franklin in 1749 during his experiments with electricity using a set of linked Leyden jar capacitors. However, the first electrochemical battery was built by Italian physicist Alessandro Volta in 1800. This battery, known as the voltaic pile, consisted of copper and zinc plates separated by brine-soaked paper disks, producing a steady current. Volta discovered that using different metals in the pile could increase the voltage.
The Daniell cell, invented by British chemist John Frederic Daniell in 1836, was the first practical source of electricity. It consisted of a copper pot filled with a copper sulfate solution, in which was immersed an unglazed earthenware container filled with sulfuric acid and a zinc electrode. These wet cells were fragile and prone to leakage, making them unsuitable for portable appliances.
Dry cells, such as the common zinc-carbon battery, offer improved safety and portability compared to early wet cells. They have a nominal voltage of 1.5 volts and are composed of a zinc anode and a carbon cathode, with an electrolyte of ammonium chloride.
The voltage of a cell is determined by the difference in standard potential between the electrodes, which equates to the force with which electrons travel between them. This is known as the cell's overall electrochemical potential. Higher voltage means more work can be done by the same number of electrons, resulting in increased power output from the battery.
Different combinations of metals in battery cells can produce varying voltage and current outputs. Some combinations deliver high voltage rapidly but cannot sustain it for long, while others produce a lower current that can be maintained for extended periods. Stacking multiple cells together can also increase the overall voltage of a battery.
Lithium-ion batteries offer several advantages over traditional lead-acid batteries, including higher power density, lighter weight, and shorter charging times. They can be charged at any time and do not exhibit the memory effect seen in nickel-cadmium batteries.
