Analog-to-digital conversion (ADC) is an electronic process that changes a continuously variable analog signal into a multilevel digital signal. This process involves converting analog signals, such as sound and light waves, into digital signals that can be used in computing. The conversion is performed by analog-to-digital converters (ADCs), which change the continuous nature of the analog signal in terms of time and amplitude to a digital signal with discrete levels or states. Digital signals are more efficient for propagation and are easier for electronic circuits to distinguish from noise. The reverse process, converting digital to analog, is performed by digital-to-analog converters (DACs).
Converts Analog Signals to Electrical Signals
| Characteristics | Values |
|---|---|
| Name | Analog-to-digital converter (ADC) |
| Function | Converts a continuously variable or analog signal into a multilevel digital signal without altering its essential content |
| Examples | Sine waves, waveforms representing human speech, signals from a conventional television camera |
| Output | Defined levels or states, usually a power of two (2, 4, 8, 16, etc.) |
| Sampling Rate | Must be at least twice its frequency to accurately depict the original signal |
| Use Cases | Digital audio and video, telephone modems, TV tuner cards, digital audio workstations, digital imaging systems, data communication |
| Resolution | Indicates the number of discrete values the converter can produce, usually expressed as audio bit depth |
| Time-Stretch ADC | Digitizes wide bandwidth analog signals by time-stretching the signal prior to digitization |
| Digital-to-Analog Converter | DAC, or D/A, performs the reverse function of converting digital to analog |
| DAC Use Cases | Music players, televisions, mobile phones, military radar systems, electric motor speed control, LED lamp dimming, high-end hi-fi systems |
Explore related products
What You'll Learn
Analog-to-digital conversion (ADC)
The output of the analog-to-digital converter has defined levels or states, which are almost always a power of two, such as 2, 4, 8, or 16. The simplest digital signals have only two states and are called binary. All whole numbers can be represented in binary form as strings of ones and zeros. The rate of new values is called the sampling rate or sampling frequency of the converter. The Nyquist-Shannon sampling theorem states that a faithful reproduction of the original signal is only possible if the sampling rate is higher than twice the highest frequency of the signal.
The process of analog-to-digital conversion involves sampling the input wave of the analog signal, which varies continuously like a sine wave. This is done by measuring the amplitude of a continuous-time signal at discrete instants, converting the continuous signal into a discrete one. There are three sampling methods: ideal sampling, natural sampling, and time-stretch analog-to-digital conversion. Ideal sampling is an instantaneous sampling of pulses from the analog signal, but it is difficult to implement in practice. Natural sampling is a more practical method, where the pulse has a finite width and retains the shape of the analog signal. Time-stretch analog-to-digital conversion (TS-ADC) digitizes a very wide bandwidth analog signal that cannot be digitized by a conventional ADC. It uses a photonic preprocessor to time-stretch the signal, slowing it down and compressing its bandwidth.
ADC technology is widely used to process video signals into digital bit streams for transmitting visual images and voice communications. It is also used in digital audio and video to reduce aliasing, or the production of a false frequency. A sample rate that is too low will result in distortion or aliasing, while a rate that is too high will use more storage and processing resources than necessary.
