The term 14-2 refers to a type of electrical wire. Specifically, it indicates a wire with two conductor wires and a ground wire, all of 14-gauge thickness. The gauge of a wire refers to its thickness or diameter, with lower numbers indicating a larger size. For example, a 10-gauge wire is thicker than a 12-gauge wire, and a 12-gauge wire is thicker than a 14-gauge wire. The gauge also determines the ampacity, or the amount of electric current a wire can safely carry, with larger gauges capable of handling higher amperage.
| Characteristics | Values |
|---|---|
| Wire gauge | 14 |
| Number of conductors | 2 |
| Ampacity | 15 amps |
| Color code | Black, white, red, white with red stripe, bare |
| Use | Running two separate circuits, 3-way/4-way switches |
Explore related products
What You'll Learn
14-2 is a type of wire
The 14-2 wire is commonly used in residential electrical projects and can be found in homes for wiring various devices and appliances. It is often used for running two separate circuits, as it includes two conductor wires and a ground wire. This configuration allows for separate and dedicated connections, ensuring proper functionality and safety.
The wire colours in a 14-2 configuration are typically standard across different batches and manufacturers. The wires usually include black, white, and red wires, with one of the white wires having a red stripe. This colour coding is important for electricians as it helps identify the different wires during installation, maintenance, or troubleshooting.
The 14-2 wire was also created to address the challenges posed by AFCI (Arc-Fault Circuit Interrupters) breakers. AFCI breakers are safety devices designed to protect against electrical fires caused by arcing faults. Traditional wiring methods, such as MWBC (Multi-Wire Branch Circuit), shared a neutral wire, which was not compatible with AFCI requirements. The 14-2 wire, with its two-hot and two-neutral configuration, provided a solution to this issue, allowing for proper wire insulation and separate circuits.
