In electrical wiring, 4/0 refers to the size of the wire, also known as the gauge. The number after the slash for wire size is always a zero, and the wire size is the number of zeros indicated by the number before the slash. For example, 4/0 is pronounced four-aught and is the largest size in the American Wire Gauge (AWG) system. This wire size is typically used for main panel feeds in large residential homes or light commercial buildings, as well as for feeding high-load electrical appliances.
Explore related products
What You'll Learn
4/0 is the size of the wires that feed a house from the power pole
The wire size 4/0, pronounced "four-aught", is a type of electrical wire used in residential power supply. It is the largest standard wire size in the American Wire Gauge (AWG) system, which consists of 40 wire sizes from #36 (smallest) to 4/0 (largest). The number after the slash for wire sizes indicates that the wire is technically a size with a number of zeros equivalent to the number before the slash. Thus, 4/0 is the size of the wires with four zeros, or 0000.
In the context of residential electrical systems, 4/0 wires are typically used as the service drop, which is the bundle of electrical cables that run from the power pole to the connection at a house. The service drop is a critical component that delivers electricity to the home. It consists of three insulated cables: live, neutral, and ground. These cables are loosely twisted around a strain relief cable, which supports their weight and relieves strain on the attachment points.
The service drop connects to the service head, also known as the service mast or masthead, at the house. The service head typically consists of a rigid steel conduit that runs up through the roof or along an exterior wall. It is topped with a weatherhead or weather cap, which has an open front facing downward to protect against rain and snow ingress. The bottom end of the service mast then connects to the home's meter base.
It is important to note that the service drop is not something that homeowners should attempt to interact with or modify. While it may not be something that people typically notice, it is crucial to understand its function in case of any issues. If the service drop goes down due to events like fallen trees or ice buildup, it can lead to a complete power shutdown in the house. In such cases, it is essential to contact the local power company for assistance.
