A contactor is a type of electrical relay used for switching an electrical circuit on or off. They are used in applications with higher current-carrying capacity and are typically built for 3-phase applications. Contactors are most commonly used with electric motors and lighting applications. They are designed to be directly connected to high-current load devices and are indispensable devices in the control of a circuit.
| Characteristics | Values |
|---|---|
| Definition | An electrically-controlled switching device |
| Function | To make or break the connection between the power supply and the load |
| Use | Switching an electrical circuit on or off |
| Applications | Electric motors, thermal evaporators, lighting, capacitor banks, heating, and other electrical loads |
| Current | Higher current-carrying capacity |
| Voltage | Powered at a much lower level than the switched circuit |
| Safety features | Arc suppression and spring-loaded contacts |
| Maintenance | Easier to maintain than relays |
| Design | Special structures for arc-suppression, provision for installation of additional contact blocks |
| Power contacts | Stationary and movable |
| Contact material | Alloys of tungsten, molybdenum, copper, and others |
| Enclosure material | Insulating materials such as Bakelite, Nylon 6, and thermosetting plastics |
| Coil voltage | 12, 24, 48, 110, 230, and 400V |
Explore related products
What You'll Learn
- Contactors are used to control electric motors, lighting, heating, capacitor banks, and more
- They are a type of relay, switching electrical circuits on or off
- They are designed for high current-carrying applications
- Contactors are indispensable for circuit control and have safety features like arc suppression
- They are configured to power on a circuit or shut down power when activated
Contactors are used to control electric motors, lighting, heating, capacitor banks, and more
Contactors are electrical devices that control the flow of current to a circuit. They are designed for applications that require a large amount of current to be switched frequently and rapidly. They are used to control electric motors, lighting, heating, capacitor banks, and more.
Electric motors are one of the most common applications for contactors. Contactors are used as magnetic starters for electric motors, providing safety features such as power cutoff, short circuit protection, overload protection, and under-voltage protection. Modern medium-voltage AC motor controllers use vacuum contactors, while high-voltage AC and DC contactors may use vacuum or inert gas to break the arc energy.
Contactors are also used in lighting control systems, particularly in high-powered lighting installations. They are often arranged in a latching configuration to lower overall power consumption. Contactors used in lighting applications typically have resistive load ratings, which are designed to handle higher current loads.
Contactors are used in heating applications to control the flow of current to heating elements. Similar to lighting applications, contactors used in heating typically have resistive load ratings to accommodate higher current requirements.
Capacitor banks are another application for contactors. Specialised contactors, known as capacitor contactors, are used for switching single or multiple capacitor banks for power factor correction. These contactors conform to specific standards and include features such as early make poles and damping resistors to limit the current value and extend the lifespan of the installation.
In summary, contactors play a crucial role in controlling electric motors, lighting, heating, capacitor banks, and other electrical loads. They are designed to handle high current applications and provide safety features in various industrial and electrical systems.
