ACLT is a series of models developed by HEIDEN power GmbH for loading rotary current systems. ACLT stands for three-phase loads, which combine three alternating current load channels in one enclosure. The three load channels can be used to load different devices in AC or DC operation or to test a rotary current system.
| Characteristics | Values |
|---|---|
| Full Form | ACross the Line |
| Used in | Water and Wastewater Industry, IEEE Articles, Architecture and Construction Sector |
| Description | Three-phase load AC-Load |
| Operating Modes | Constant Current, Constant Resistance, Constant Power, Constant Voltage |
| Connection | Combine 3 channels or phases in one enclosure |
| Interface | Ethernet, USB, RS-232, CAN, I/O |
Explore related products
What You'll Learn
ACLT is a three-phase load
ACLT stands for three-phase loads, which combine three alternating current load channels in one enclosure. The ACL series supports DC voltage and AC voltage up to 1,000 Hz loads. The three-phase load systems, or ACLT, combine three channels or phases in one enclosure.
The ACLT series models were developed for loading rotary current systems. The three load channels can be used to load three different DUTs in AC or DC operation or to test a rotary current system. The maximum load current can be increased by connecting several channels of a rotary current device ACLT in parallel.
The ACL series loads have the following operating modes: constant current, constant resistance, constant power, and constant voltage (CC, CR, CP, and CV mode). In ACL mode, the load current mode has a set waveform independent of the input voltage. In resistance mode, the height and waveform of the current depend on the input voltage. In power and voltage mode, the power or voltage is controlled by adjusting the input current.
The ACLT combines three channels or phases in one enclosure. Ethernet, USB, RS-232, CAN, I/O interface, and a system bus for master-slave connection are built in serially, while the GPIB interface is available as an option. The programming is done in SCPI with an extensive command syntax.
