CR is an abbreviation that is used in electrical drawings and diagrams. In the context of electrical engineering, CR is thought to be an antiquated designation for a diode, a component that conducts current primarily in one direction. While the letter D is now more commonly used to refer to diodes, CR was once the preferred term, especially when silicon was a novel material.
Explore related products
What You'll Learn
CR could refer to a switch or diode
In electrical engineering, CR can refer to a control relay, a type of switch. A relay is a remotely controlled electric switch that can be turned on or off, opening or closing a circuit. Relays are commonly used in testing equipment, such as a solar cell tester, where they can be used to switch between different tests.
CR can also refer to a current rectifier, or diode. Diodes are a type of electronic component that can rectify current, only allowing the flow of current in one direction. Diodes can be made from crystalline silicon semiconductors, or from other materials such as germanium or selenium.
The use of CR as a reference designator for these components is not standardized, but it is a commonly used convention. Reference designators are used to unambiguously identify the location and type of a component within an electrical schematic or on a printed circuit board. They typically consist of one or two letters followed by a number, with the letters indicating the type of component. For example, C typically refers to a capacitor, R to a resistor, and K to a relay.
It is important to note that the specific meaning of CR in any given electrical drawing or schematic will depend on the context and the specific components being used. It may be necessary to refer to additional documentation or information to fully understand the intended meaning of CR in a particular case.
