CTL, or Circuit Total Limiting, is a feature of electrical panels that limits the number of tandem circuit breakers that can be installed. This feature was first mandated by the 1965 edition of the National Electrical Code (NEC) to prevent overloading and the potential risk of fire. Non-CTL breakers, which predate CTL circuit breakers, are still produced for older electrical installations that do not have CTL features.
Explore related products
What You'll Learn
CTL stands for Circuit Total Limiting
Tandem breakers are 2-in-1 breakers that can double the number of available circuits in a panel board. Before the introduction of CTL, there was no restriction on the number of tandem breakers that could be installed in a panel board, leading to potential overloading and safety hazards. With CTL, electrical panels are designed to have sections that allow single circuit breakers in some slots and CTL tandem circuit breakers in others. The distribution of these slots can be checked in the diagram provided by the panel manufacturer.
It's important to note that CTL breakers come in two main types: CH and BR breakers. CH breakers, made by Cutler Hammer, are slimmer, have tan or black handles, and come with a lifetime warranty. On the other hand, BR breakers, made by Bryant, are thicker, have black handles, and offer a 10-year warranty. Both types are CTL breakers, but it's essential to ensure compatibility with your specific panel.
Non-CTL breakers are still available and used for older electrical installations that do not have CTL features. These non-CTL tandem breakers are labelled for "replacement use only" and are not approved for use in CTL assemblies. However, using these non-CTL breakers can lead to unsafe situations as they can bypass the rejection feature, resulting in panel overloading.
In summary, CTL, or Circuit Total Limiting, is an essential safety feature in modern electrical panels that helps prevent overloading and potential fire hazards by limiting the total number of circuit breakers, including tandem breakers, that can be installed.
