Impedance is a measure of the opposition to electrical flow in a circuit or part of a circuit. It is denoted by the symbol Z and measured in ohms. In electrical engineering, impedance is the result of the combined effect of resistance and reactance in a circuit. The impedance of a circuit element can be defined as the ratio of the phasor voltage across the element to the phasor current through the element. It is important to note that impedance is only observed for AC signals, not for DC signals, where impedance and resistance are the same.
Explore related products
$26.19
What You'll Learn
Impedance is the opposition to alternating current
In electrical engineering, impedance is the opposition to alternating current presented by the combined effect of resistance and reactance in a circuit. The impedance of a circuit element can be defined as the ratio of the phasor voltage across the element to the phasor current through the element, as determined by their relative amplitudes and phases. In a two-terminal circuit element, the impedance is the ratio of the complex representation of the sinusoidal voltage between its terminals to the complex representation of the current flowing through it. It depends on the frequency of the sinusoidal voltage.
The impedance of a circuit is influenced by its resistive (R) and reactive (X) components. The resistive component arises from collisions of the current-carrying charged particles with the internal structure of the conductor. The reactive component, on the other hand, is an additional opposition to the movement of electric charge due to changing magnetic and electric fields in circuits with alternating current.
Impedance can be calculated using the rules for combining impedances in series and parallel. For components connected in series, the total impedance is the sum of the individual component impedances. Impedance can be measured using an LCR meter, which measures a component's inductance (L), capacitance (C), and resistance (R). These values can then be used to calculate the impedance at any frequency.
Understanding Electrical Phase Alignment: Out-of-Phase Conditions Explained
You may want to see also
Explore related products
Impedance includes resistance and reactance
Impedance is a measure of the total opposition that a circuit or a part of a circuit presents to electric current. It is measured in ohms and is represented by the symbol Z. Impedance includes both resistance and reactance.
Resistance (R) is a force that tends to resist the flow of electrical current. It is created by a resistor to achieve some effect. The more resistive a resistor is, the more it restricts the flow of electricity through it. Resistance is usually measured in ohms and is defined as the voltage across an element divided by the current (R = V/I).
Reactance (X) is an additional opposition to the movement of electric charge that arises from the changing magnetic and electric fields in circuits carrying alternating current. It is an unfortunate by-product of certain electrical components. There are two basic types of reactance: capacitive reactance and inductive reactance. Capacitive reactance is created by capacitors, while inductive reactance is created by inductors. Reactance is also expressed in ohms and it behaves in much the same way as resistance, in that it tends to restrict the flow of current through a circuit.
The impedance of a circuit is the square root of the sum of the squares of the resistance and reactance. In other words, impedance can be represented as the hypotenuse of a right triangle, with resistance and reactance as the shorter sides.
In electrical engineering, impedance is the opposition to alternating current presented by the combined effect of resistance and reactance in a circuit. It is useful for performing AC analysis of electrical networks, as it allows relating sinusoidal voltages and currents by a simple linear law.
