In the context of electric tables, IMC stands for Intermediate Metal Conduit, while EMT stands for Electrical Metallic Tubing. Both are types of steel conduits used to protect electrical conductors and wiring systems. IMC is a cross between EMT and Rigid Metal Conduit (RMC) and is defined as a steel raceway designed for protecting and routing conductors and cables. EMT, on the other hand, is commonly known as thin-wall and is a steel raceway of circular cross-section that is unthreaded.
IMC and EMT Characteristics
| Characteristics | IMC | EMT |
|---|---|---|
| Full Form | Intermediate Metal Conduit | Electrical Metallic Tubing |
| Type | Thinner, lightweight version of rigid metal conduit | Thinnest and lightest-weight steel conduit |
| Material | Steel | Galvanized steel or aluminium |
| Threaded | Yes | No |
| Temperature Range | N/A | -30°C to 60°C |
| Installation | Requires couplings, connectors, and grounding practices | Requires couplings, fittings, and setscrew or compression-type fasteners |
| Use | Protecting and routing conductors and cables | Protecting and routing electrical wiring |
| Protection | Requires corrosion protection | Coated to resist corrosion |
| Cost | N/A | More affordable than RMC and IMC |
Explore related products
What You'll Learn
EMT is a type of Electrical Metallic Tubing
EMT, or Electrical Metallic Tubing, is a type of electrical conduit made of metal tubing that is used to protect and route electrical wiring in a building or structure. EMT is commonly used in commercial and industrial buildings, although it can also be used for residential applications. It is typically made of coated steel or aluminium and is available in a range of colours and sizes, with common sizes including 1/2-inch, 3/4-inch, 1-inch, and up to 4 inches. EMT is also known as "thin-wall" conduit because it is thin and lightweight compared to other types of conduits, such as RMC (rigid metal conduit).
One of the advantages of EMT is its ease of installation. It can be bent with a simple tool called a conduit bender and is installed with couplings and fittings that are secured with setscrew or compression-type fasteners. EMT is also less costly than other types of conduits, such as GRC (galvanized rigid conduit).
EMT is similar to IMC (Intermediate Metal Conduit), which is also a type of steel tubing. However, IMC is heavier than EMT but lighter than RMC. IMC is defined as a steel raceway designed to protect and route conductors and cables, and it has specific guidelines for installation, including environmental factors and corrosion protection requirements.
In summary, EMT is a versatile, cost-effective, and lightweight option for electrical conduit, making it a popular choice for a variety of applications, from residential to commercial and industrial buildings. Its ease of installation and flexibility make it a convenient choice for protecting and routing electrical wiring.
Explore related products
IMC is a type of Intermediate Metal Conduit
IMC stands for Intermediate Metal Conduit. It is a type of electrical conduit, which is a metal or plastic pipe through which electrical wires are run. Conduits are used to protect electrical wires and are used in exposed locations, unfinished areas, and surface-mounted installations outdoors.
IMC is a heavy-duty conduit made of galvanized steel. It is designed to protect and route conductors and cables. IMC is a thinner, lighter-weight version of rigid metal conduit (RMC) and is approved for use in all the same applications as RMC. It has a slightly thinner gauge than RMC, making it easier to work with and more common in new construction. IMC is also threaded like RMC, so the same couplings can be used for both.
The Florida Electrical Code 2020 outlines the specifications and guidelines for the use and installation of IMC. This includes conditions under which IMC can be installed, such as environmental factors and corrosion protection requirements. It also specifies size limitations, the maximum number of conductors allowed, and guidelines for making bends and securing the conduit.
IMC is often used for the structural piping that houses the wiring for a home's connection to utility service lines for overhead services. It is protected by zinc and organic coatings inside and out and is tested for bendability and threadability before being shipped.
Explore related products
EMT is also known as 'thin-wall'
EMT, or electrical metallic tubing, is known as "thin-wall" conduit because it is thin and lightweight compared to other conduits like RMC. EMT is approximately 40% thinner in wall thickness than RMC, which makes it lighter and easier to handle. EMT is commonly made from galvanized steel or aluminium, while RMC is made from heavier steel, making it stronger than EMT.
EMT is not threaded and is instead used with threaded fittings that clamp to it. It is connected to equipment and other lengths of conduit using clamp-type fittings. EMT is available in trade sizes 1/2", 3/4", and 1", as well as 10' and 20' lengths. It is also available in a range of colours for easy system identification.
EMT is generally more common in commercial and industrial buildings than in residential applications. It is often used in areas where minimal physical protection is needed, and it is flexible for installations where minor adjustments in the layout may be necessary. EMT is also rigid and can be bent with a simple tool called a conduit bender.
While EMT is thin-walled, there are other types of thin-walled conduits used for electrical wiring. For example, electrical nonmetallic tubing (ENT) is a thin-walled corrugated tubing that is moisture-resistant and flame retardant. It is pliable and can be bent by hand. Flexible metallic conduit (FMC) is another example of a thin-walled conduit, which is made by the helical coiling of a self-interlocked ribbed strip of aluminium or steel.
Explore related products
IMC is a cross between EMT and RMC
Electrical conduits are channels used to protect and route conductors and cables. Intermediate metal conduits (IMC) are a type of electrical conduit that is a cross between electrical metal tubing (EMT) and rigid metal conduits (RMC). IMC is a thinner-walled and lightweight version of RMC, making it easier to work with and more common in new construction. It is approved for use in all applications where RMC is permitted.
IMC is made of stronger steel, allowing it to have thinner walls while maintaining equivalent or greater strength than RMC. This results in a larger inside diameter, which can be beneficial for wire pulling and fill. The thinner walls of IMC also make it more prone to buckling, kinking, and crushing during threading and bending.
In terms of protection, IMC has a zinc and organic coating on its interior and exterior surfaces, providing corrosion resistance. The interior coating is a "UL-listed, corrosion-resistant, organic or inorganic coating", while the exterior is galvanized. RMC, on the other hand, is galvanized inside and out.
EMT is also a type of rigid electrical conduit commonly made of galvanized steel or aluminum. It is called "thin-wall" conduit due to its lightweight and thin nature compared to RMC. EMT is installed with couplings and fittings secured with setscrews or compression-type fasteners. It is commonly used for exposed indoor wiring runs in residential and light commercial construction.
Overall, IMC offers the benefits of both EMT and RMC, combining the ease of use and lightweight nature of EMT with the strength and versatility of RMC.
Explore related products
EMT and IMC are both made of ferrous metal
EMT (electrical metallic tubing) and IMC (intermediate metal conduit) are two types of electrical conduits, which are vital for protecting wiring systems within buildings and infrastructure. They are both made of ferrous metal and serve to protect electrical wiring. However, they differ in terms of material, thickness, weight, strength, durability, cost, and suitability for different environments.
EMT is a lightweight steel conduit with a thin wall construction, making it easy to handle and reducing physical strain on installers. Its thinner walls also contribute to reduced material costs. EMT is typically designed to handle a temperature range from about -10°C to 60°C (14°F to 140°F), although this can vary depending on the raw materials used. It is important to note that while EMT is non-flammable, it can be affected by extreme heat and may lose its structural integrity. EMT is commonly used for exposed indoor wiring runs in residential and light commercial construction.
On the other hand, IMC is a threaded steel raceway with a thinner wall and weighs about one-third less than RMC (rigid metal conduit). It is designed to protect and route conductors and cables. IMC can be used for the same applications as RMC but is lighter and easier to work with, making it more common in new construction. The standard finished length of IMC, with coupling, is 10 feet.
Both EMT and IMC have protective coatings to prevent corrosion. EMT typically has a zinc-based outer coating and a corrosion-resistant organic inner coating. IMC also has a zinc-based outer coating and an approved organic corrosion-resistant inner coating.
In summary, EMT and IMC are both made of ferrous metal and serve as electrical conduits, protecting electrical wiring. They differ in their specific characteristics, such as weight, thickness, temperature resistance, and suitability for different environments.
Frequently asked questions
IMC stands for Intermediate Metal Conduit. It is a steel raceway designed to protect and route conductors and cables. It is lighter and has a thinner wall than RMC (Rigid Metal Conduit) but is still strong.
EMT stands for Electrical Metallic Tubing. It is commonly called thin-wall and is a steel raceway of circular cross-section. It is unthreaded and normally 10 feet long.
IMC is a cross between EMT and RMC. It is slightly thinner than RMC but is threaded like RMC, so the same couplings can be used for both. EMT, on the other hand, is unthreaded and has a zinc-based outer coating and a corrosion-resistant organic inner coating.
