A standard switch in electricity is a device that can disconnect or connect the conducting path in an electrical circuit, interrupting the electric current or diverting it from one conductor to another. The most common type of switch is an electromechanical device with one or more sets of electrical contacts, connected to external circuits. When a pair of contacts is touching, the current can pass between them; when they are separated, no current can flow. The most familiar form of a switch is manually operated, like a light switch or a computer keyboard button. However, switches can also be automatically operated to control machine motions, such as a garage door opening and closing.
Explore related products
What You'll Learn
- Types of switches: SPST, SPDT, electronic, electromechanical, latching relay, etc
- Switch functions: connecting/disconnecting circuits, controlling lights/appliances, sensing
- Switch operation: momentary, alternate, time-delay, manual, automatic
- Switch considerations: current, voltage, size, robustness, resistance, ratings
- Switch styles: toggle, rocker, slider, push-button, single/double/triple-pole, etc
Types of switches: SPST, SPDT, electronic, electromechanical, latching relay, etc
A standard switch in electricity is a device that can disconnect or connect the conducting path in an electrical circuit, interrupting or diverting the electric current. Switches are made in various configurations and can be operated manually or automatically. They can also function as sensing elements to detect the position of a machine part, liquid level, pressure, or temperature.
There are several types of switches, including:
- SPST (Single-Pole Single-Throw): The simplest type of switch, with one pole and one throw. SPST switches control a single circuit and can connect to one output, making them ideal for applications that need only an on/off state.
- SPDT (Single-Pole Double-Throw): These switches have one pole and two throws, allowing them to route one input circuit to one of two output circuits. SPDT switches are useful for selecting between two options.
- DPST (Double-Pole Single-Throw): These switches are equivalent to a pair of SPST switches or relays actuated by a single coil. They have two poles and one throw.
- DPDT (Double-Pole Double-Throw): DPDT switches have two poles and two throws, making them equivalent to two SPDT switches or relays actuated by a single coil.
- Electronic switches: These switches use electrical signals to control operations and make decisions. They are equipped with a mechanism to disconnect the circuit in the event of an overload.
- Electromechanical switches: These switches bridge the gap between electronic and mechanical switches. They are electrically operated but rely on mechanical contacts as the switching mechanism. Examples include the traditional relay, electromechanical crossbar, and Strowger switch.
- Latching relay: A type of electromechanical switch that maintains its state after being actuated. It does not have a default position and can retain its position regardless of the power supply. Latching relays are useful in applications where power consumption needs to be limited or where interrupted power should not affect the controlled circuits.
When selecting a switch, it is essential to consider its ratings, such as the current rating, which indicates the maximum electric current the switch is designed to carry. Other factors to consider include the size, robustness, environmental resistance, and power handling capacity of the switch.
