In electrical wiring, the terms line and load are used to refer to the wires that deliver and carry power. Line wires are those that feed electricity from the source to a device, while load wires carry the power onwards to other devices further along the circuit. Line wires are always hot, meaning they are carrying an electrical current, while load wires are broader in definition, carrying electricity from a terminal point to the point of use.
Explore related products
What You'll Learn
- Line wires carry electricity from the power source to the load
- Line wires are always hot, meaning they carry an electrical current
- Line wires are usually black, but this is not always the case
- Line wires are insulated and often colour-coded to prevent accidental contact
- Load wires carry electricity from one terminal point to the point of use
Line wires carry electricity from the power source to the load
In the electrical trades, the terms "line" and "load" are shorthand words that refer to the electrical wires that deliver power from the source to a device (line) and carry power onward to other devices further along the circuit (load). Line wires are always "hot", meaning they are carrying an electrical current. They are the "supply lines" of electrical power.
Line wires carry electricity from the power source to the electrical panel, while load wires distribute that power to various devices. The line is the incoming electricity, and the load is the outgoing electricity. The line wire is the input to the light switch, and the load wire carries the power from the switch to the light. When the switch is cut off, the power is cut to the light.
In a series of outlets wired in sequence, the load wire is the wire that feeds electricity from the first outlet to the remaining boxes on the same line. The load wire is a bit broader in definition, but in short, it’s the wire that continues to carry the electricity from some terminal point to the point of use.
Line wires are usually black, and load wires are usually white, but this is not always the case. Electrical wires are coated with colour-coded insulation to protect from shock and indicate the wire's purpose, but this colour-coding system is not standardised.
