In the context of electrical fittings, LL stands for Left, indicating a 90-degree turn to the left. This term is used to describe electrical fittings that are used with conduits or EMTs, which allow for a change in direction. In a three-phase power system, LL can also refer to L2, which, along with L1 and L3, designates the three different hot legs in the system.
| Characteristics | Values |
|---|---|
| LL in electrical fittings | 90-degree change in direction with conduit exit point on the left |
| L in inductance | Represents the pioneering work in electromagnetism by Heinrich Lenz |
| L1, L2, and L3 | Designations related to 3-phase power |
| L (Live) | Refers to the unearthed conductive part of the AC main supply |
Explore related products
$6.46
$6.99
What You'll Learn
- LL can refer to electrical fittings used with conduits or EMT, allowing a 90-degree change in direction
- In a three-phase power system, L1, L2, and L3 designate the three different hot legs
- LL can stand for Live and Neutral on an AC input terminal
- The symbol L in inductance was chosen to honour Heinrich Lenz's pioneering work in electromagnetism
- LL can refer to the direction of the conduit exit point, meaning L for Left
LL can refer to electrical fittings used with conduits or EMT, allowing a 90-degree change in direction
In electrical language, LL refers to electrical fittings used with conduits or EMT, allowing for a 90-degree change in direction. These fittings have an oblong shape with a cover on the long side, allowing wire access for pulling. The first letter "L" stands for "el", indicating a 90-degree turn, while the second letter specifies the direction of the conduit exit point: "B"ack, "L"eft, or "R"ight.
To visualize the direction, imagine holding the fitting vertically with the cover facing you and the conduit entry on the long dimension at the top. If the second conduit entry, or the short dimension, exits to the left, it is referred to as "LL". If it exits to the back, it is "LB", and if it exits to the right, it is "LR".
These fittings are essential in electrical work as they enable wires to make 90-degree turns while maintaining easy access for adjustments. This flexibility is crucial for navigating wires through tight spaces and ensuring they reach their intended destinations.
It is important to correctly identify the direction of the conduit exit point, as indicated by the second letter, to ensure proper installation and function. Mistakenly using an "LL" fitting when an "LB" or "LR" is required can result in wiring challenges and potential safety hazards. Therefore, understanding the meaning of LL in this context is crucial for electricians and anyone working with electrical systems.
