In electrical wiring, the terms line and load are used to describe the two points of connection for a device within a circuit. The line refers to the wire that carries power from the source to a device, while the load refers to the wire that moves that power to the next device in the circuit. The load is the component of a circuit that consumes power or energy. In a household setting, examples of electrical loads include light bulbs and appliances.
Explore related products
What You'll Learn
Line wires are usually black, load wires are usually white
In electrical wiring, the terms "line" and "load" refer to wires that deliver and carry power. The line wire delivers power from the source to a device, while the load wire carries power onward to other devices further along the circuit. The line wire is the input to the light switch, while the load wire carries power from the switch to the light fixture.
Line wires are typically black, while load wires are usually white. However, this colour scheme is not always followed, and there are several other factors to consider when identifying line and load wires. For example, line wires are usually located at the bottom of a panel or device, while load wires are typically found at the top. Line wires are always "hot", meaning they carry an electrical current, while load wires only carry a charge when they are in use.
The colour of electrical wires is important as it indicates the wire's function. In the US, the National Electrical Code (NEC) designates the colour code for electrical cables. "Hot" cables, which carry an electrical current, are typically black, red, or blue. In the case of higher-voltage lines, orange may also be used to indicate a "hot" cable. White or grey wires are neutral, while green or green with a yellow stripe indicates a ground wire.
It is important to correctly identify line and load wires for safety reasons. When installing outlets, switches, or circuit breakers, wires must be connected correctly to avoid short circuits or damage to electrical components. Understanding the difference between line and load wires is also crucial for troubleshooting and maintenance of electrical systems.
