PFC is a term used in electrics to refer to Prospective Fault Current, which is a test designed to calculate the maximum current that will flow within a fault loop path during an electrical fault. This test is important to ensure that protective devices within a circuit, such as circuit breakers and fuses, are rated at the correct breaking capacity to safely protect the circuit. PFC is also used to refer to Power Factor Correction, which is a set of mechanisms built into a power supply circuit to raise the power factor and improve energy efficiency.
| Characteristics | Values |
|---|---|
| Full Form | Prospective Fault Current |
| Other Full Forms | Power Factor Correction, Power Factor Controller |
| Purpose | Calculate the maximum current that will flow within a fault loop path during an electrical fault |
| Test Process | 1. Use Prospective Fault Current tester or select the PFC function of a multifunctional tester such as the Megger 1553, and make sure that the supply is ON, but the Main Switch is in OFF position. 2. Connect the test leads on the Line and Neutral terminals of the Main Switch, as well as on the Earth terminal. 3. Press TEST and make note of the reading (kA). For three-phase installations, test each phase separately and double the measured reading. |
| Result | The result can be determined by calculation, ascertained by inquiry to the relevant electricity board, or measured using a Loop Tester. |
| Comparison with PSC | PSC will be higher than PFC on TT and TN-S systems, but on a TNC-S system, both should be identical. |
| Protective Devices | Devices such as circuit breakers and fuses must have an interrupting rating that exceeds the prospective short-circuit current to safely protect the circuit from a fault. |
| Power Factor Correction | A set of mechanisms built into a power supply circuit to raise the power factor. |
Explore related products
What You'll Learn
- PFC stands for Prospective Fault Current
- PFC tests are conducted to calculate the maximum current during an electrical fault
- PFC value is compared with the breaking capacity of protective devices within the installation
- PFC is also used to refer to Power Factor Correction
- PFC mechanisms are used to reduce reactive power and increase energy efficiency
PFC stands for Prospective Fault Current
The Prospective Fault Current test is carried out with the supply turned on but the main switch turned off. Test leads are connected to the line and neutral terminals of the main switch, as well as the earth terminal. The test is then performed, and the reading is noted in kiloamperes (kA). For three-phase installations, each phase is tested separately, and the measured reading is doubled.
The PFC test specifically calculates the current that will flow in the event of an earth fault, i.e. line to earth. This is in contrast to the PSC (Prospective Short Circuit) test, which calculates the current in the event of a short circuit between live conductors.
The results of the PFC test are used to ensure that protective devices within a circuit, such as circuit breakers and fuses, are rated at the correct breaking capacity. If the breaking capacity of a fuse or circuit breaker is exceeded, it can lead to equipment damage, fire, or explosion.
It is important to note that the earthing conductor, main protective bonding conductors, and circuit protective conductors should all be connected during these tests. The presence of these conductors can impact the impedance of the earth fault loop and, consequently, the level of prospective fault current.
