The acronym SES has several meanings in electrical terms, including Standard Electrical System, Service Entrance Section, and Static Excitation System. SES can refer to a pre-wired electrical system in workstations, providing ease of access with duplex receptacles and eliminating the need for on-site hard wiring. It can also refer to the service entrance section in electrical installations or the static excitation system in electrical engineering.
| Characteristics | Values |
|---|---|
| Full Form | Standard Electrical System |
| Supplies | Single 15 amp electrical circuit |
| Pre-wired | Yes |
| Receptacles | Duplex receptacles in the uprights for ease of access |
| Interconnect cords | Connect the circuit in one upright to the circuit in another upright within a single workstation |
| Power cords | 8-foot power cord |
| Service | Service Entrance Section |
| Engineering | Static Excitation System |
Explore related products
What You'll Learn
SES is an acronym for Standard Electrical System
The Standard Electrical System offers a range of options for customisation and configuration. The starter unit, for example, features standard 15-amp electrical receptacles (outlets) on the inside trim panel. The specific number and arrangement of receptacles can vary depending on the upright height. For instance, uprights measuring 60", 72", and 84" are equipped with four receptacles (two duplexes) on the inside metal trim panel, while 48" uprights have two receptacles (one duplex) on each side.
It's important to note that outside upright trim panels do not have receptacles and are typically made of laminate rather than metal. When planning accessory additions, it's crucial to consider that SES receptacles protrude slightly. The height of the worksurface when adjusting the height of SES workstations should also be taken into account, as the starting height should not exceed 30" from the floor.
SES benches are designed for convenience and ease of use. They come with an 8-foot power cord, and no additional wiring is required. The power cord is first plugged into the upright and then into the power source. Each SES bench is designed to function independently, as individual SES benches cannot be interconnected.
MOPD in Electrical Engineering: Understanding Its Meaning and Applications
You may want to see also
Explore related products
It supplies a single 15-amp electrical circuit
SES stands for Standard Electrical System or Service Entrance Section. It supplies a single 15-amp electrical circuit in the uprights of a single or double-sided workstation.
A 15-amp circuit is a type of electrical circuit that can supply a maximum of 15 amperes of current. It is a common type of circuit found in residential homes and powers most standard, everyday appliances. These circuits are designed to handle appliances that draw less than 15 amps and typically have electrical conductors (wires) that are not large enough for appliances that draw more than 15 amps.
The National Electrical Code (NEC) requires that 15-amp circuits use 15-amp receptacles. This is because the receptacle rating, which describes the amperage a receptacle can handle, must match the circuit rating. Using a 20-amp receptacle on a 15-amp circuit is a code violation and can be unsafe, as it may trip the breaker.
The 15-amp receptacles used in SES workstations have a standard design with two outlets, each having a long (neutral) slot, a shorter (hot) slot, and a half-round grounding hole. These receptacles are pre-wired in the uprights of the workstation for ease of access and to eliminate the time and cost of on-site hard wiring.
Overall, the SES system provides a convenient and safe way to supply power to a single or double-sided workstation, ensuring compatibility with most standard appliances and adhering to the necessary electrical codes.
Redevicing in Electrical: What Does It Mean?
You may want to see also
SES is pre-wired at the factory
SES stands for Standard Electrical System, which is a division of Treston. The Standard Electrical System (SES) supplies a single 15-amp electrical circuit in the uprights of a single or double-sided workstation.
The SES is pre-wired at the factory, which has several benefits. Firstly, it eliminates the time and cost of on-site hard wiring. The pre-wiring ensures that the workstation is ready for use with minimal setup required upon receipt. This is because the workstation is pre-wired with duplex receptacles in the uprights for ease of access. The pre-wired connector in the right upright of a starter unit accepts the power cord and the interconnect cord, while the left upright has a connector for the other end of the interconnect cord.
The interconnect cord is used to connect the circuit in one upright to another within a single workstation, running under the worksurface. This allows for a seamless and efficient power supply to the workstation.
Pre-wiring at the factory also ensures consistency and quality control, as all SES units are assembled and wired according to the same specifications. This reduces the risk of errors or variations that may occur during on-site wiring.
In addition, pre-wiring simplifies the installation process, making it quicker and more efficient. This is particularly advantageous for large-scale deployments or when time is a critical factor.
Overall, the fact that SES is pre-wired at the factory enhances the convenience, efficiency, and reliability of the Standard Electrical System.
Understanding the Basics of Non-Static Electricity
You may want to see also
It has receptacles in the uprights for easy access
SES stands for Standard Electrical System, a division of Treston by IAC Industries. SES supplies a single 15-amp electrical circuit in the uprights of a single or double-sided workstation. The system is pre-wired at the factory, eliminating the need for on-site hard wiring, saving time and cost.
The key advantage of SES is that the workstation is pre-wired with receptacles in the uprights, providing easy access to power outlets. These receptacles protrude slightly from the uprights, and their placement must be considered when planning accessory additions. The SES system includes both starter and add-on benches, each equipped with its own 8-foot power cord.
The starter unit of an SES system features standard 15-amp electrical receptacles (outlets) on the inside trim panel of each upright. The number of receptacles varies depending on the upright height. For upright heights of 60", 72", and 84", there are four receptacles in two duplexes on the inside metal trim panel. Uprights measuring 48" have two receptacles in a single duplex on each inside metal trim panel.
When adding an upright to an existing SES configuration, it is important to note that the outside trim panels of these uprights do not have any receptacles and are typically made of laminate. The interconnect cord, included with the starter and add-on benches, is used to connect the circuits in multiple uprights within a single workstation, ensuring a continuous power supply.
Renewable Electricity: Powering the Future with Sustainable Energy Sources
You may want to see also
SES benches include an 8-foot power cord
SES, or Standard Electrical System, is a system that supplies a single 15-amp electrical circuit in the uprights of a single or double-sided workstation. It is pre-wired at the factory to save time and cost and includes receptacles or outlets for ease of access.
The SES system is designed to be user-friendly and efficient. Each SES starter and add-on bench includes its own 8-foot power cord, eliminating the need for any additional wiring. This power cord is first plugged into the upright and then into the power source, providing a simple and convenient way to access electricity.
The 8-foot power cord included with SES benches offers a generous length that allows for flexible placement of the workstation. It can be easily connected to the pre-wired connector in the upright, ensuring a safe and secure power supply. This feature makes the SES benches a convenient choice for various work environments, providing ample room for manoeuvring and configuring the workspace.
It is important to note that individual SES benches cannot be interconnected. However, when an add-on unit is installed, it serves as the middle upright, allowing for configuration options. The interconnect cord, which is used to connect the circuit between uprights within a single workstation, further enhances the flexibility of the SES system.
Overall, the inclusion of an 8-foot power cord with SES benches contributes to the system's ease of use and adaptability, making it a versatile option for powering workstations in different settings.
